NM01ADP53/8MD

The SIUI UT Angle Probe is a highly adaptable and precise ultrasonic transducer designed for non-destructive testing (NDT) applications requiring versatile angled beam inspections. A key feature of this probe is its replaceable wedge design, which allows for quick and efficient changes in inspection angles and adaptation to various materials without needing to change the probe body itself. Operating at a frequency of 5 MHz, this probe delivers excellent resolution, making it ideal for detecting small flaws and discontinuities. The 3/8" (9.5mm) transducer element produces a focused ultrasonic beam, ensuring enhanced sensitivity and accuracy. Equipped with a Microdot connector, this probe ensures a secure and reliable connection to ultrasonic testing instruments. Manufactured by SIUI, a trusted leader in NDT equipment, this angle probe offers exceptional performance and adaptability for critical inspections.

Key Features and Benefits:

• Replaceable Wedge Design:

  • Allows for rapid changes in inspection angles and adaptation to different materials.

  • Provides maximum flexibility for diverse inspection requirements.

• 5 MHz Operating Frequency:

  • Offers excellent resolution for detecting small flaws and discontinuities.

  • Ideal for detailed inspections.

• 3/8" (9.5mm) Transducer Element:

  • Creates a focused ultrasonic beam for enhanced sensitivity and accuracy.

  • Provides effective defect detection.

• Microdot Connector:

  • Ensures a secure and reliable connection to ultrasonic testing instruments.

  • Minimizes signal loss and interference.

• SIUI Manufacturing:

  • Manufactured by a reputable provider of NDT equipment, ensuring high quality and durability.

  • Provides confidence in performance and reliability.

Applications:

• Weld Inspection:

  • Adapting to various weld configurations with interchangeable wedges.

  • Detecting cracks, lack of fusion, and other weld defects.

• Pipeline Inspection:

  • Inspecting pipelines for corrosion, cracks, and other flaws with adaptable angles.

• Aerospace Manufacturing:

  • Inspecting critical components for defects and ensuring material integrity.

• Automotive Manufacturing:

  • Inspecting welds and components for quality control.

• General Non-Destructive Testing (NDT):

  • Performing versatile angled beam inspections with adaptable wedges.
