STANDARD SHEAR WAVE TRANSDUCERS ( SS ), 0.750" X 0.750", 5 MHZ, RESOLUTION, BNC, DAKOTA NDT
The Dakota NDT Standard Shear Wave Transducer (SS) is a high-resolution ultrasonic transducer featuring a 0.750 x 0.750 inch (3/4" x 3/4") element and a center frequency of 5 MHz. Designed for a wide range of general angle beam inspections where enhanced resolution is critical, this transducer is typically employed with angle beam wedges (available separately) to introduce shear waves into the test material at various refracted angles. It is equipped with a standard BNC connector for easy integration with most ultrasonic flaw detectors.
The 5 MHz frequency of this transducer provides superior resolution, making it ideal for applications requiring the detection and characterization of very small discontinuities. When used in conjunction with appropriate angle beam wedges, it offers a reliable solution for detailed weld inspections and general flaw detection across a multitude of materials where high resolution is paramount. The "Resolution" damping further ensures clear signal separation, crucial for accurate defect characterization.
Key Selling Points:
High-Resolution Angle Beam Inspection: Specifically designed for applications demanding superior resolution in shear wave inspections.
Enhanced Detection of Small Flaws: The 5 MHz frequency offers exceptional capability for detecting and resolving minute discontinuities.
Versatile Application with Wedges: Compatible with a range of angle beam wedges (sold separately) to achieve various inspection angles.
Standard BNC Connector: Ensures easy and direct connectivity with a wide variety of common ultrasonic testing instruments.
Reliable Performance by Dakota NDT: Backed by a trusted manufacturer in the non-destructive testing industry.
"Resolution" Damping: Provides clear signal separation for accurate defect characterization.
Benefits:
Exceptional Detection of Small Discontinuities: The high frequency and "Resolution" damping enhance the ability to identify very fine flaws and material anomalies.
Flexibility in Inspection Angles: When combined with appropriate wedges, it allows for comprehensive inspection from various angles with high clarity.
Ensures Compatibility with Common UT Instruments: The BNC connector provides broad compatibility.
Provides Highly Detailed Inspection Data: Delivers superior resolution for precise material evaluation and flaw characterization.
Approximate Dimensions (inches):
Element Size: 0.750 inches x 0.750 inches (3/4" x 3/4")
Overall Length (without wedge): Approximately 1.0 to 1.5 inches (This dimension can vary slightly depending on the specific model).
Body Diameter: Approximately 0.75 to 1.0 inches (This can vary slightly depending on the specific model).
Connector Type: BNC
Applications:
This high-resolution standard shear wave transducer is commonly utilized for:
Detailed angle beam weld inspection where the detection of very small defects is critical.
Flaw detection in pipes, tubing, and other critical components requiring the highest possible resolution.
Inspection of various materials using angle beam techniques to detect minute flaws at different orientations when used with appropriate wedges.
Applications where precise flaw sizing and characterization are paramount due to the high resolution capabilities.
