NM01T7062405

The Dakota NDT Magnetic Bolting Transducer (3/4", 5 MHz, Microdot Connector) is a specialized ultrasonic transducer designed for the precise and reliable measurement of elongation in ferromagnetic bolts using ultrasonic bolt tension monitoring instruments. Its key feature is a strong magnetic base, ensuring secure, repeatable, and efficient coupling to the end of the bolt, which is critical for accurate readings.

With a 3/4 inch (0.75 inch) diameter, this transducer provides an optimal contact area for effective signal transmission into a variety of ferromagnetic bolt sizes. The 5 MHz frequency offers an excellent balance of penetration capability and resolution, ideal for the typical length ranges encountered in bolting applications. The industry-standard Microdot connector ensures a secure and reliable connection to most ultrasonic bolt tension monitors.

As a single element transducer, it transmits and receives ultrasonic waves directly through the bolt material. This technology allows for the non-destructive measurement of the change in length (elongation) of the bolt as tension is applied, providing accurate data for calculating crucial parameters such as load, stress, and strain.

Key Selling Points:

• Secure Magnetic Coupling: Ensures consistent and reliable attachment to ferromagnetic bolts for repeatable measurements.

• Optimized for Bolt Measurement: 5 MHz frequency provides an ideal balance of penetration and resolution for typical bolt dimensions.

• Versatile Application: Suitable for a range of ferromagnetic bolt sizes.

• Accurate Tension Monitoring: Enables precise measurement of bolt elongation, crucial for determining correct tension.

• Durable and Reliable: Designed for demanding industrial environments.

Benefits:

• Ensures Proper Bolt Tension: Facilitates accurate measurement and verification of bolt pre-load, enhancing structural integrity and safety.

• Increases Efficiency: Provides a quick and non-destructive method for assessing bolt tension.

• Improves Joint Reliability: Accurate tensioning helps prevent failures and ensures the long-term performance of bolted connections.

• Easy to Use: The magnetic base simplifies attachment, and the Microdot connector is widely compatible.

Applications:

• Precise measurement and monitoring of bolt tension in critical structures and machinery.

• Quality control during the installation and maintenance of bolted joints.

• Verification of proper pre-load in a wide range of industrial applications, including construction, manufacturing, and infrastructure.

• Ideal for use with ultrasonic bolt tension monitoring instruments to ensure accurate and reliable results.
