Portable Panoramic X-Ray Flaw Detector (Ceramic Tube) — XXGH-3505Z
High-Power 360° Industrial Radiography System for Pipeline Inspection SKU: XXGH-3505ZOverview
The XXGH-3505Z Portable Panoramic X-Ray System is a high-performance industrial radiography solution designed for circumferential inspection of pipelines and cylindrical components. Featuring a ceramic X-ray tube and a 360° × 30° radiation field, this system enables efficient panoramic exposure, reducing inspection time and improving productivity.
With an adjustable output voltage range of 180–350 kV and a penetration capability of up to 50 mm in A3 steel, the XXGH-3505Z is ideal for demanding inspection tasks in oil & gas, construction, and fabrication industries. Its compact yet rugged design allows for reliable field deployment in harsh environments.
The system includes a portable generator and controller unit, providing flexibility, control, and consistent radiographic performance for critical weld inspections.
What's Included
| Item | Details |
|---|---|
| X-Ray Generator | XXGH-3505Z panoramic ceramic tube unit |
| Controller | Portable control unit |
| Cables | Connection cables |
| Documentation | User manual |
Box Dimensions & Shipping Weight (Estimated)
| Parameter | Imperial |
|---|---|
| Generator Size | 13.4 × 13.4 × 28.3 in |
| Controller Size | 12.2 × 12.2 × 5.3 in |
| Generator Weight | 83.8 lb |
| Controller Weight | 18.7 lb |
Key Specifications
| Parameter | Details |
|---|---|
| Model | XXGH-3505Z |
| Output Voltage | 180 – 350 kV |
| Input Power | 3.5 kW |
| Focus Size | 1.0 × 2.4 mm |
| Radiation Angle | 360° × 30° |
| Max Penetration | 50 mm (A3 steel) |
| Tube Type | Ceramic |
| Operation | Portable system |
Performance Features
Panoramic Radiation (360°)
Enables full circumferential inspection in a single exposure.
High Penetration Capability
Up to 50 mm steel penetration for demanding applications.
Ceramic Tube Technology
Provides stable performance and long service life.
Compact Portable Design
Suitable for field deployment and pipeline inspection.
User-Friendly Design
- Portable generator and controller units
- Easy setup and operation
- Efficient inspection workflow
- Designed for field radiography
Built for Industrial Environments
- Rugged construction for harsh conditions
- Reliable performance in field operations
- Suitable for continuous industrial use
- Designed for professional radiography applications
Compatibility
Compatible with:
- Industrial X-ray film and digital radiography systems
- Radiographic accessories (cassettes, IQIs, markers)
- Pipeline inspection setups
- NDT radiography workflows
Ideal Applications
- Pipeline circumferential weld inspection
- Oil & gas field radiography
- Pressure vessel inspection
- Structural weld inspection
- Fabrication and construction
- Industrial radiographic testing
About the Product
The XXGH-3505Z panoramic X-ray system delivers efficient, high-penetration radiographic inspection with full circumferential coverage, making it an essential solution for pipeline and industrial NDT applications.
