NM01Z1600003
MMX-7 Ultrasonics NDT Gauge, Field Calibration of all materials, High Speed Scanning, and Back Lite Display. Alarm Mode, Dual Multi Mode, and Data Output port. Thru-Paint range: 0.100” – 1.0”, coating max: .040”. Time Based B-Scan, Data Logger – Stores 12000 readings & waveforms. Unit includes Transfer Cables & Software. Includes 5MHz HD probe. Dakota NDT SKU: Z-160-0003
Choose Quantity
Dakota NDT MMX-7 Multi-Mode Ultrasonic Thickness Gauge
SKU: Z-160-0003
A multi-mode ultrasonic thickness gauge with thru-paint measurement, time-based B-scan and a 12,000-reading data logger, made for corrosion monitoring and wall thickness inspection.
| 2Measurement modes | 12,000Readings and waveforms | 0.001"Resolution | 5 MHzHD probe included |
The Dakota NDT MMX-7 is a multi-mode ultrasonic thickness gauge for corrosion monitoring, wall loss evaluation and field calibration on a wide range of materials. Inspectors can switch between pulse-echo mode for pits and flaws and echo-echo mode for measuring through paint and coatings, using one highly damped dual-element probe for both.
A time-based B-scan shows a cross-section of the test material, and the internal data logger stores 12,000 readings with their waveforms. The kit includes a 5 MHz HD probe, PC software and transfer cables, all packed into a rugged, sealed aluminum gauge.
Key Features
 | Dual-element accuracyThe included 5 MHz HD dual-element probe has one crystal to transmit and one to receive, separated by an acoustic barrier. This creates a V-shaped sound path, which the gauge corrects for to give an accurate thickness reading, with a built-in transducer table for improved linearity. |
Two measurement modes in one gauge
Pulse-echo mode detects pits and flaws. Echo-echo thru-paint mode ignores the coating and measures only the base material, from 0.100" to 1.0" with coatings up to 0.040", so less surface preparation is needed.
Time-based B-scan
The B-scan view displays a cross-section of the test material, giving a graphical profile of the bottom surface for corrosion mapping and wall loss evaluation.
12,000-reading data logger
Store readings together with their waveforms, then transfer them through the data output port using the included PC software and cables.
High-speed scan and alarm mode
Scan mode captures readings quickly as you move across the surface. Alarm mode lets you set high and low limits, with a visual and audible warning when a reading falls outside them.
Custom setups and calibration
Store up to 64 custom setups alongside factory setups for common applications. Calibrate with single or two-point calibration, or pick a basic material type, and choose low, medium or high gain for different materials.
Rugged sealed case
An extruded aluminum body with gasket-sealed, nickel-plated end caps protects the gauge in demanding field conditions, and the backlit display stays readable in low light.
Specifications
| General | |
| Manufacturer | Dakota NDT |
|---|---|
| Model | MMX-7 |
| SKU | Z-160-0003 |
| Instrument type | Multi-mode ultrasonic thickness gauge |
| Shipping dimensions (estimated) | 356 × 305 × 152 mm (14.0 × 12.0 × 6.0 in) |
| Shipping weight (estimated) | 2.3 kg (5.0 lb) |
| Measurement | |
| Measurement modes | Pulse-echo (pits and flaws); echo-echo (thru-paint) |
| Thru-paint range | 0.100" to 1.0" (2.54 to 25.4 mm) |
| Maximum coating thickness | 0.040" (1.0 mm) |
| Resolution | 0.001" (0.01 mm) |
| Velocity range | 0.0122 to 0.7300 in/µs (309.88 to 18,542 m/s) |
| Calibration | Single or two-point, or selection of basic material types |
| Gain | Low, medium and high settings; AGC in multi-mode |
| Display & Data | |
| Display | Backlit graphic display |
| Display views | Large digits and time-based B-scan |
| Data logger | 12,000 readings and waveforms |
| Setups | 64 custom user setups, plus factory setups |
| Alarm | High and low limits, visual and audible |
| Data output | Data output port, with PC software and transfer cables included |
| Probe & Build | |
| Probe | 5 MHz HD (highly damped) dual-element, included |
| Case | Extruded aluminum body, nickel-plated aluminum end caps, gasket sealed |
| Calibration standard | Factory calibrated to NIST and MIL-STD-45662A |
What's in the Box
- Dakota NDT MMX-7 ultrasonic thickness gauge
- 5 MHz HD dual-element probe
- PC software and data transfer cables
Contents can vary by package, so contact us to confirm what ships with your order.
Complete your thickness testing setup
Add couplant and a step calibration block for daily checks, plus extra Dakota dual-element transducers for other thickness ranges or high-temperature work. A protective rubber boot adds impact protection in the field.
Applications
The MMX-7 suits corrosion surveys and wall thickness checks in the field, the shop and maintenance programs.
| ✓ Corrosion and pitting | ✓ Tube and pipe |
| ✓ Tanks | ✓ Boilers and pressure vessels |
| ✓ Thru-paint inspection of coated structures | ✓ Wall loss evaluation |
| ✓ Time-based B-scan surveys | ✓ Maintenance and asset integrity programs |
Downloads
| ⬇ Operating Manual (PDF) |
About Dakota NDT
Dakota NDT manufactures high-quality industrial ultrasonic testing equipment for the petrochemical, aerospace, power generation and automotive industries. Its range includes corrosion and precision thickness gauges, flaw detectors, bolt tension monitors, transducers and accessories.
