ADELIX ADL-UT25: Advanced Ultrasonic Thickness Gauge with Echo-Echo-Echo Capability

The ADELIX ADL-UT25 is a professional-grade ultrasonic thickness gauge designed to deliver unparalleled accuracy and versatility in a single, robust package. This comprehensive kit provides a complete solution for inspecting a wide range of materials, including those with existing coatings.

Key Features & Benefits

• Advanced Echo-Echo-Echo Measurement: The standout feature of this gauge is its Echo-Echo-Echo (E-E-E) measurement mode. This powerful technology allows you to accurately measure the true material thickness of a component through existing paint, coatings, or rust without the need for costly and time-consuming removal. It saves time, reduces effort, and prevents damage to the component's surface.




• Three High-Performance Probes: This kit includes three specialized probes, making it a versatile tool for any job:

  • S112-2.5-12/2 (2.5 MHz Dual Element): Ideal for inspecting thick or coarse-grained materials like cast iron and composites, offering excellent sound penetration.

  • S112-5-10/2-A-05 (5 MHz Dual Element): A general-purpose probe that provides a perfect balance of penetration and high resolution for a wide range of standard applications.

  • S111-5-K12 (5 MHz Single Element): Designed for high-precision measurement on uncoated materials where the highest level of accuracy is required.

• Complete Kit for Immediate Use: This kit comes with everything you need to start inspecting immediately, including multiple probes, a calibration block, and all necessary accessories.

• Durable & Portable: The instrument and accessories are housed in a nylon transport case, ensuring the equipment is protected and easily transported to any job site.

Included in This Kit

• 1 x ADELIX ADL-UT25 Ultrasonic Thickness Gauge

• 3 x Ultrasonic Probes:

  • 1 x S112-2.5-12/2

  • 1 x S112-5-10/2-A-05

  • 1 x S111-5-K12

• UT Cables for probe connection

• 1 x 4-Step Calibration Block

• 1 x Nylon Transport Case

• Operating Manual and Certificate

Technical Specifications

• Manufacturer: ADELIX




• Model: ADL-UT25

• Measurement Modes: Echo-Echo-Echo (E-E-E) and Single Echo

• Measurement Range: Varies by probe and material

• Display: High-resolution digital display

Ideal For

• Corrosion Monitoring

• Pipeline and Tank Inspection

• Ship and Vessel Maintenance

• Manufacturing Quality Control

• On-site and In-service Inspections
