Hexalon — Cut Lead Screen (4.5" × 17", 0.005")
Precision Lead Screen for Industrial Radiographic Film Imaging SKU: LS45X17X005Overview
The Hexalon Cut Lead Screen is a radiographic imaging accessory designed for use in industrial X-ray and gamma radiography applications. Measuring 4.5" × 17" with a 0.005" thickness, this lead screen helps improve radiographic image quality by supporting film exposure control and reducing the effects of scattered radiation.
Used with industrial radiographic film, lead screens help enhance image definition, improve contrast, and support consistent inspection results during weld, pipeline, tank, casting, and component radiography. The narrow 4.5" × 17" cut-size format is especially practical for weld seam inspection, pipe radiography, and elongated exposure setups.
Built for professional NDT workflows, the Hexalon LS45X17X005 is ideal for radiography teams requiring reliable lead screen materials for film-based inspection applications.
What's Included
| Item | Details |
|---|---|
| Lead Screen | Cut lead screen, 4.5" × 17", 0.005" thick |
Box Dimensions & Shipping Weight (Estimated)
| Parameter | Imperial |
|---|---|
| Length | 18.0 in |
| Width | 5.0 in |
| Height | 1.0 in |
| Dimensions (L × W × H) | 18.0 × 5.0 × 1.0 in |
| Weight | 0.8 lb |
Key Specifications
| Parameter | Details |
|---|---|
| Product Type | Radiographic lead screen |
| Screen Type | Cut lead screen |
| Size | 4.5" × 17" |
| Thickness | 0.005" |
| Application | Industrial radiographic film imaging |
| Manufacturer | Hexalon |
| SKU | LS45X17X005 |
Performance Features
Radiographic Image Support
Helps improve film imaging performance during industrial radiographic testing.
Scatter Radiation Reduction
Supports clearer radiographs by helping reduce the effects of scattered radiation.
0.005" Lead Thickness
Provides a thin lead screen configuration for specific radiographic film techniques.
Narrow Cut-Size Format
4.5" × 17" size is practical for weld seams, pipe inspection, and elongated radiographic exposures.
User-Friendly Design
- Pre-cut format for convenient use
- Narrow profile for weld and pipe radiography
- Easy to place with compatible film setups
- Designed for efficient film-based RT workflows
Built for Industrial Environments
- Suitable for professional radiography inspection programs
- Practical for field, shop, and darkroom workflows
- Designed for repeated inspection support
- Built for industrial NDT applications
Compatibility
Compatible with:
- Industrial radiographic film
- X-ray radiography workflows
- Gamma radiography workflows
- Film cassettes and exposure setups
- Weld, pipe, casting, and component inspection programs
Ideal Applications
- Industrial radiographic testing
- Weld seam inspection
- Pipeline radiography
- Tank and vessel inspection
- Casting and forging inspection
- Film-based NDT workflows
- Field and shop radiography support
About Hexalon
Hexalon provides radiographic inspection accessories and consumables designed to support professional NDT workflows. Their products help inspection teams maintain reliable film handling, imaging quality, and practical performance in industrial radiography applications.
