NM010601220

Detailed Description:

This is a specialized, intrinsically safe probe cable designed for use with the Cygnus 1 Ex ultrasonic thickness gauge and the T5BH-EX ultrasonic transducer probe. It serves as the vital connection between the probe and the gauge, transmitting electrical signals necessary for accurate ultrasonic thickness measurements.

Key Features and Specifications:

• Intrinsically Safe Design:

  • The cable is specifically engineered for use in potentially explosive atmospheres. The "Ex" designation in both the probe and gauge names signifies that this cable is part of a system designed to prevent electrical sparks or thermal effects that could ignite flammable gases or vapors.




• T5BH-EX Probe Compatibility:

  • This cable is precisely matched to the T5BH-EX ultrasonic transducer probe, ensuring optimal signal transmission and performance.




• Cygnus 1 Ex Gauge Compatibility:

  • It is designed for seamless integration with the Cygnus 1 Ex ultrasonic thickness gauge, maintaining the integrity of the intrinsically safe system.




• 1.3 Meter Length:

  • The cable measures 1.3 meters (approximately 4.26 feet) in length, providing a practical balance between reach and manageability during inspections.




• Durable Construction:

  • The cable is constructed with robust materials to withstand the rigors of industrial environments, including potential exposure to oils, chemicals, and mechanical stress.




• Shielded Design:

  • The cable is likely shielded to minimize electromagnetic interference, ensuring accurate and reliable signal transmission.




• Connector Types:

  • It will have specific connectors on each end, that are designed to connect to the T5BH-EX probe, and the Cygnus 1 Ex gauge.




• Manufacturer:

  • Produced by Cygnus Instruments, a reputable manufacturer of ultrasonic thickness gauges and related accessories.

Applications:

• This cable is essential for conducting ultrasonic thickness measurements in hazardous locations, including:




  • Offshore oil and gas platforms.

  • Petrochemical refineries.

  • Chemical processing plants.

  • Any environment where flammable gases or vapors may be present.

Importance:

• The intrinsically safe design of this cable is critical for ensuring the safety of personnel and equipment in hazardous environments.

• Its compatibility with the Cygnus 1 Ex gauge and T5BH-EX probe ensures accurate and reliable ultrasonic thickness measurements.
