NM01FG3642

The Circle Safe 850A is a water-based, dual response magnetic particle inspection (MPI) material that is Ready to Use (RTU) and conveniently packaged in a 1 quart sprayer bottle. This product from Circle Systems offers versatility by providing both visible and fluorescent indications for detecting surface and near-surface discontinuities in ferromagnetic materials.

The "dual response" characteristic means that the particles in the 850A are red in color for excellent visibility under normal white light conditions. Additionally, these particles will fluoresce a bright yellow-green when viewed under UV-A (black) light. This dual capability provides inspectors with flexibility to choose the most effective lighting for their specific inspection environment and enhances the detectability of fine flaws.

Being water-based, Circle Safe 850A offers a safer and more environmentally friendly alternative to oil-based products. The ready-to-use formulation eliminates the need for mixing concentrates, ensuring consistent particle concentration and saving valuable preparation time. The 1 quart sprayer bottle provides a convenient and portable method for applying the magnetic particle suspension directly to the inspection surface.

Key Features:

• Dual Response: Red particles visible under white light and bright yellow-green fluorescence under UV-A light.

• Ready to Use (RTU): No mixing required, ensuring consistent and optimal particle concentration.

• Water-Based: Offers a safer and more environmentally friendly inspection solution.

• Convenient 1 Quart Sprayer Bottle: Provides easy and direct application to the inspection area.

• High Sensitivity: Designed to reveal fine surface and near-surface discontinuities.

• Certified Quality: Particles meet or exceed relevant industry specifications.

• Wide Application Temperature Range: Typically suitable for use between 32-120°F (0-49°C).

Benefits:

• Enhanced Defect Detection: Dual visibility under both white and UV-A light provides greater versatility and sensitivity.

• Saves Time and Labor: The ready-to-use formula streamlines the inspection process.

• Improved Workplace Safety: Water-based formulation reduces potential hazards.

• Portable and Easy to Use: The sprayer bottle allows for convenient application in various inspection settings.

• Ensures Reliable Results: Consistent particle concentration and certified quality provide confidence in inspection outcomes.

Applications:

• Inspection of machined component parts for surface and near-surface discontinuities.

• Quality control during manufacturing processes.

• Maintenance inspections of ferromagnetic equipment and structures.

• Field inspections where portability and ease of use are essential.

• Situations where both visible and fluorescent inspection methods may be beneficial.
