SNAIL (AWS TYPE) ANGLE BEAM WEDGES ( SNW ), .625" X .625", 45 DEG, DAKOTA ".625" X .625", 45 DEG ONLY" SKU: SNW6245D
Choose Quantity
Dakota NDT — Snail (AWS Type) Angle Beam Wedge SNW6245D (45°, 5/8" × 5/8")
Compact UT Wedge for Precision Weld Inspection Applications SKU: SNW6245DOverview
The Dakota NDT SNW6245D Snail (AWS Type) Angle Beam Wedge is a compact ultrasonic wedge designed for precise weld inspection using 5/8" × 5/8" probes. Configured to generate a 45° refracted shear wave, this wedge is ideal for detecting and evaluating common weld discontinuities such as cracks, lack of fusion, and inclusions.
The “snail” design provides excellent maneuverability, allowing inspectors to access tight or restricted areas with ease. Its compact geometry ensures stable probe positioning and consistent beam entry, supporting accurate and repeatable inspection results.
Built for compatibility with Dakota NDT systems and standard ultrasonic setups, this wedge is widely used in fabrication, structural inspection, and welding quality control applications.
What's Included
| Item | Details |
|---|---|
| UT Wedge | SNW6245D snail angle beam wedge, 45°, 5/8" × 5/8" |
Box Dimensions & Shipping Weight (Estimated)
| Parameter | Imperial |
|---|---|
| Length | 5.0 in |
| Width | 4.0 in |
| Height | 3.0 in |
| Dimensions (L × W × H) | 5.0 × 4.0 × 3.0 in |
| Weight | 0.6 lb |
Key Specifications
| Parameter | Details |
|---|---|
| Product Type | Ultrasonic wedge |
| Wedge Type | Snail (AWS Type) |
| Angle | 45° refracted shear wave |
| Probe Size Compatibility | 5/8" × 5/8" |
| Model | SNW6245D |
| Application | Angle beam ultrasonic testing |
Performance Features
45° Angle Beam Inspection
Optimized for weld inspection and detection of common discontinuities.
Snail Design for Accessibility
Compact form allows inspection in confined or hard-to-reach areas.
Stable Beam Entry
Ensures consistent coupling and reliable ultrasonic transmission.
Repeatable Results
Supports accurate and dependable inspection performance.
User-Friendly Design
- Compact and easy to handle
- Simple probe mounting
- Lightweight for extended use
- Designed for efficient inspection workflows
Built for Industrial Environments
- Durable construction for demanding applications
- Suitable for field and shop inspections
- Reliable performance in continuous use
- Designed for professional NDT workflows
Compatibility
Compatible with:
- Dakota NDT ultrasonic probes
- Standard UT flaw detectors
- Angle beam inspection setups
- AWS-based weld inspection procedures
Ideal Applications
- Weld inspection and flaw detection
- Structural steel inspection
- Pipeline and pressure vessel inspection
- Fabrication and welding QA/QC
- Oil & gas and construction industries
- General angle beam ultrasonic testing (UT)
About Dakota NDT
Dakota NDT is a trusted manufacturer of ultrasonic testing equipment and accessories, known for delivering reliable and high-performance solutions for industrial inspection. Their products are widely used in applications where durability, accuracy, and efficiency are essential.
