The Sonatest X3A-5M64E-06X10-SQX5 is a state-of-the-art, long array phased array ultrasonic probe designed for advanced electronic scanning applications in non-destructive testing (NDT). Part of Sonatest's X3 series, this probe is engineered to deliver exceptional performance and high-resolution imaging for demanding inspection tasks.

This probe operates at a frequency of 5 MHz, offering a balance between penetration depth and resolution, making it suitable for a wide range of materials and inspection scenarios. The defining feature of this probe is its 64-element linear array configuration. This high element count enables highly precise electronic beam steering, focusing, and shaping, allowing for detailed and comprehensive inspections.

The individual element dimensions of 0.6 mm pitch and 10 mm elevation contribute to the probe's superior beam control and imaging capabilities. The 0.6 mm pitch enables high-resolution inspections, allowing for the detection and characterization of even the smallest flaws. The 10 mm elevation optimizes the beam profile for enhanced sensitivity and coverage, ensuring thorough inspections of large areas.

The SQX5 connector provides a secure and reliable connection to phased array ultrasonic testing instruments, ensuring optimal signal transmission and data integrity. This connector type is designed for robust performance in industrial settings, minimizing signal loss and ensuring consistent results.

Constructed from high-quality materials and built to stringent manufacturing standards, the Sonatest X3A-5M64E-06X10-SQX5 probe is designed for durability and long-term performance. It is engineered to withstand the rigors of field inspections and provide consistent, reliable results over time.

Key Features and Benefits:

• 5 MHz Frequency: Provides a balance of penetration and resolution.

• 64-Element Linear Array: Enables highly precise electronic beam steering and focusing.

• 0.6 mm Pitch: Offers high-resolution inspection capabilities.

• 10 mm Elevation: Optimizes beam profile for enhanced sensitivity and coverage.

• SQX5 Connector: Provides a secure and reliable connection.

• Robust Construction: Ensures durability and long-term performance.

• Sonatest Quality: Manufactured by a reputable provider of NDT equipment.

• Long Array: Enables fast scanning of large areas.

Applications:

• Advanced Phased Array Ultrasonic Testing (PAUT): Applications requiring precise electronic scanning and high-resolution imaging.

• Large Weld Inspection (PAUT): Thorough inspection of large welds.

• Complex Geometry Inspection (PAUT): Inspection of complex shapes and difficult-to-access areas.

• Aerospace Industry (PAUT): Inspection of large composite structures.

• Power Generation Industry (PAUT): Inspection of large pressure vessels.
