NM0325250

The EHS Male Type “K” T/C Plug is a crucial component for creating reliable and quick connections with Type K thermocouples. This plug is designed to easily interface with female Type K thermocouple connectors or jacks, allowing for rapid connection and disconnection of temperature sensing probes and instrumentation.

Type K thermocouples are a widely used temperature sensor known for their broad temperature range (-200°C to +1260°C or -328°F to +2300°F), good linearity, and robust performance. The Male Type “K” T/C Plug is specifically constructed with materials that are compatible with the Chromel (+) and Alumel (-) alloys that comprise Type K thermocouples. This ensures accurate temperature readings by maintaining the thermoelectric properties of the connection.

The body of the plug is typically color-coded yellow according to industry standards, making it easily identifiable as a Type K connector. It features two polarized pins to ensure correct polarity when mating with a female connector, preventing potential errors in temperature measurement.

Key Features:

• Type K Compatibility: Specifically designed for use with Type K thermocouples.

• Male Connector: Plugs into female Type K thermocouple jacks or connectors.

• Color-Coded Yellow: For easy identification as a Type K connector.

• Polarized Pins: Ensures correct polarity for accurate readings.

• Durable Construction: Built to withstand typical industrial and laboratory environments.

• Easy to Wire: Designed for simple and secure connection to thermocouple wire.

Benefits:

• Quick Connections: Enables fast and easy connection and disconnection of thermocouple sensors.

• Accurate Readings: Maintains the thermoelectric integrity of the Type K circuit.

• Easy Identification: Standard yellow color-coding prevents misconnections.

• Reliable Performance: Ensures a secure and stable electrical connection.

• Versatile Use: Suitable for a wide range of temperature sensing applications.

Applications:

• Connecting Type K thermocouple probes to temperature indicators, controllers, and data loggers.

• Creating extension cables for Type K thermocouples.

• Building custom temperature measurement setups.

• Industrial process control and monitoring.

• Laboratory and research applications.

• HVAC and environmental testing.
