Dolphitec — TRM-ECx 1.5 MHz Transducer Module (12 mm Aqualene)
Low-Frequency Ultrasonic Inspection Module for Composite & Material Evaluation SKU: C-00-2-29Overview
The Dolphitec TRM-ECx 1.5 MHz Transducer Module is a specialized ultrasonic inspection component designed for advanced NDT applications involving composites, bonded structures, and engineered materials. Operating at 1.5 MHz, this module provides enhanced penetration capability for thicker or more attenuative materials where lower-frequency ultrasonic inspection is preferred.
Equipped with a 12 mm Aqualene interface, the TRM-ECx supports stable acoustic coupling and reliable ultrasonic signal transmission during inspection. This configuration helps maintain consistent contact and repeatable results when evaluating layered structures, composite panels, and bonded assemblies.
Built for compatibility with Dolphitec inspection systems, this module is ideal for aerospace, manufacturing, research, and quality control environments where dependable ultrasonic imaging and material assessment are essential.
What's Included
| Item | Details |
|---|---|
| Transducer Module | TRM-ECx 1.5 MHz module with 12 mm Aqualene interface |
Box Dimensions & Shipping Weight (Estimated)
| Parameter | Imperial |
|---|---|
| Length | 8.0 in |
| Width | 6.0 in |
| Height | 3.0 in |
| Dimensions (L × W × H) | 8.0 × 6.0 × 3.0 in |
| Weight | 1.0 lb |
Key Specifications
| Parameter | Details |
|---|---|
| Product Type | Ultrasonic transducer module |
| Model | TRM-ECx |
| Frequency | 1.5 MHz |
| Interface Material | Aqualene |
| Aqualene Thickness / Size | 12 mm |
| Application | Ultrasonic inspection and material evaluation |
| Manufacturer | Dolphitec |
| SKU | C-00-2-29 |
Performance Features
Low-Frequency 1.5 MHz Operation
Provides improved penetration for thicker or more attenuative materials.
12 mm Aqualene Interface
Supports stable coupling and consistent ultrasonic signal transmission.
Composite Inspection Support
Designed for evaluating composites, bonded structures, and engineered materials.
Reliable Signal Performance
Helps deliver repeatable inspection results in professional NDT workflows.
User-Friendly Design
- Designed for integration with compatible Dolphitec systems
- Compact module format for practical inspection use
- Stable contact interface for consistent scanning
- Supports efficient material evaluation workflows
Built for Industrial Environments
- Reliable performance for professional NDT applications
- Suitable for laboratory, production, and field inspection settings
- Designed for repeated inspection use
- Built for composite and advanced material workflows
Compatibility
Compatible with:
- Dolphitec ultrasonic inspection systems
- Composite inspection workflows
- Bonded structure evaluation procedures
- Material testing and QA/QC programs
Ideal Applications
- Thick composite material inspection
- Bonded structure evaluation
- Laminate and layered material assessment
- Aerospace component inspection
- Manufacturing quality control
- Research and development testing
- Advanced ultrasonic NDT workflows
About Dolphitec
Dolphitec develops advanced ultrasonic inspection technology for composite materials, bonded structures, and industrial NDT applications. Their systems and transducer modules are used where accurate imaging, repeatable results, and dependable material evaluation are essential.
