W10-N55S-SWPC Wedge (55° Shear Wave, 2" AOD Radius)
Curved Surface UT Wedge for Small Pipe & Weld Inspection Applications SKU: W10-N55S-SWPC-2" AODOverview
The W10-N55S-SWPC 2" AOD Wedge is a precision ultrasonic testing wedge designed for shear wave inspection on small curved outside diameter surfaces. Configured for 55° shear wave inspection, this wedge supports reliable weld inspection, flaw detection, and ultrasonic scanning on small pipe and cylindrical components.
Featuring a 2" AOD radius, the wedge is shaped to maintain stable contact and consistent coupling on tighter curved surfaces. This helps improve ultrasonic signal transmission and supports repeatable inspection results during pipe weld, tube, vessel, and structural component evaluations.
Built for professional NDT workflows, this wedge is ideal for field and shop applications where accurate angle beam inspection on small diameter curved components is required.
What's Included
| Item | Details |
|---|---|
| UT Wedge | W10-N55S-SWPC wedge, 55° shear wave, 2" AOD radius |
Box Dimensions & Shipping Weight (Estimated)
| Parameter | Imperial |
|---|---|
| Length | 6.0 in |
| Width | 5.0 in |
| Height | 3.0 in |
| Dimensions (L × W × H) | 6.0 × 5.0 × 3.0 in |
| Weight | 0.8 lb |
Key Specifications
| Parameter | Details |
|---|---|
| Product Type | Ultrasonic wedge |
| Model | W10-N55S-SWPC |
| Beam Type | Shear wave |
| Angle | 55° |
| Radius | 2" AOD |
| Surface Type | Curved outside diameter |
| Application | Angle beam ultrasonic testing |
| SKU | W10-N55S-SWPC-2" AOD |
Performance Features
55° Shear Wave Inspection
Supports weld inspection and detection of internal discontinuities.
2" AOD Radius
Designed for stable contact on small curved pipe and cylindrical surfaces.
Consistent Beam Transmission
Helps maintain reliable ultrasonic performance during angle beam inspections.
Curved Surface Compatibility
Improves coupling and probe positioning on tight outside diameter inspection areas.
User-Friendly Design
- Easy probe mounting and positioning
- Curved profile for improved surface contact
- Compact and durable wedge body
- Designed for efficient ultrasonic inspection workflows
Built for Industrial Environments
- Durable construction for repeated inspection use
- Reliable performance in field and shop conditions
- Suitable for pipe, tube, vessel, and weld inspection
- Designed for professional NDT workflows
Compatibility
Compatible with:
- W10-style ultrasonic probes
- Angle beam ultrasonic inspection setups
- Ultrasonic flaw detectors
- Small pipe and curved surface UT workflows
Ideal Applications
- Small diameter pipe weld inspection
- Tube and curved surface ultrasonic testing
- Pressure vessel inspection
- Structural weld flaw detection
- Oil & gas and power generation inspection
- General angle beam UT applications
About the Product
The W10-N55S-SWPC 2" AOD Wedge is designed to provide reliable shear wave inspection performance on small curved outside diameter surfaces, helping inspectors achieve stable coupling, accurate beam entry, and repeatable flaw detection results.
