NM01QC260CT

The QUICK CHANGE WEDGE, 1/2", 60*, CT is a crucial component designed for use with quick change tool post systems, commonly found on lathes. This wedge plays a vital role in the rapid and secure exchange of cutting tools, contributing to increased efficiency and precision in machining operations.

Key Features:

• Integral to Quick Change Systems: This wedge is specifically engineered to function within a quick change tool post setup. These systems allow machinists to swap out various cutting tools swiftly without the need for extensive realignment of the tool height after each change.

• Sizing for 1/2" Capacity: The "1/2"" designation likely indicates the intended capacity or size of the tool holder that this wedge is designed to operate with. It typically suggests that the wedge is suitable for securing tool holders that can accommodate cutting tools with shank diameters up to 1/2 inch.

• 60-Degree Angle: The "60*" refers to the precise angle of the wedge's inclined surfaces. This angle is critical to the wedge's function, as it determines the mechanical advantage and locking force applied to the tool holder when it is engaged within the tool post. A 60-degree angle is a common geometry for providing a strong and reliable clamping action.

• Designation "CT": The "CT" suffix likely serves as a specific identifier for this particular wedge. It could denote:

  • A specific manufacturer or brand: Many manufacturers of machining accessories use unique codes to identify their products. "CT" could be an initialism for the producing company or a product line.

  • A specific type or series: Within a manufacturer's range of quick change wedges, "CT" might distinguish this specific model based on material, finish, or minor design variations.

  • A classification related to the intended application or compatible tool post series.

Applications:

• Securing tool holders within quick change tool posts on lathes.

• Facilitating the rapid and repeatable exchange of various cutting tools during machining processes.

• Maintaining consistent tool height and alignment after tool changes, reducing setup time and improving accuracy.

• Used in a wide range of turning, facing, threading, and other lathe operations.

Importance:

• Enables significant time savings in machining by allowing for fast tool changes.

• Contributes to improved accuracy and repeatability by minimizing the need for tool height adjustments after each change.

• Enhances the efficiency of lathe operations, allowing machinists to perform a wider variety of tasks with less downtime.

• Provides a secure and rigid mounting for cutting tools, contributing to better surface finishes and dimensional accuracy.
