Hexalon — Cut Lead Screen (4.5" × 8.5", 0.005")
Radiographic Lead Screen for Industrial X-Ray Film Applications SKU: LS45X85X005Overview
The Hexalon Cut Lead Screen is a precision radiography accessory designed to support clear and consistent image quality during industrial X-ray film inspections. Sized at 4.5" × 8.5" with a thickness of 0.005", this lead screen helps improve radiographic contrast while reducing the effects of scattered radiation.
Used in direct contact with industrial radiographic film, the lead screen assists in producing sharper images for weld, pipe, casting, and structural inspections. Its thinner 0.005" profile is suitable for applications where lighter lead screen backing is preferred while still maintaining effective image enhancement.
Pre-cut for convenience, this screen is easy to place inside compatible film holders and cassettes, making it ideal for professional radiographic testing workflows.
What's Included
| Item | Details |
|---|---|
| Lead Screen | Hexalon cut lead screen, 4.5" × 8.5", 0.005" thick |
Box Dimensions & Shipping Weight (Estimated)
| Parameter | Imperial |
|---|---|
| Length | 9.0 in |
| Width | 5.0 in |
| Height | 1.0 in |
| Dimensions (L × W × H) | 9.0 × 5.0 × 1.0 in |
| Weight | 0.4 lb |
Key Specifications
| Parameter | Details |
|---|---|
| Product Type | Radiographic lead screen |
| Material | Lead |
| Size | 4.5" × 8.5" |
| Thickness | 0.005" |
| Format | Pre-cut screen |
| Application | Industrial radiography |
Performance Features
Enhanced Image Contrast
Helps improve radiographic image definition and inspection visibility.
Scatter Radiation Reduction
Supports cleaner X-ray film results by reducing unwanted scatter effects.
Thin 0.005" Profile
Provides lightweight lead screen support for film radiography applications.
Precision Cut Format
Pre-cut size allows quick placement in compatible film holders and cassettes.
User-Friendly Design
- Easy to place with radiographic film
- Compact and lightweight
- Suitable for field and lab radiography
- Designed for efficient inspection workflows
Built for Industrial Environments
- Durable for repeated radiographic use
- Reliable performance in field inspection conditions
- Suitable for professional RT workflows
- Designed for consistent image quality
Compatibility
Compatible with:
- Industrial X-ray film
- Vinyl film holder cassettes
- Radiographic inspection setups
- Weld, pipe, and structural RT workflows
Ideal Applications
- Industrial radiographic testing
- Weld inspection and quality control
- Pipeline and pressure vessel radiography
- Oil & gas and fabrication inspection
- Aerospace and manufacturing QA/QC
- General X-ray film imaging support
About Hexalon
Hexalon provides radiographic accessories designed to support professional industrial X-ray inspection workflows. Their lead screens and film-handling products help improve image quality, consistency, and reliability in demanding NDT applications.
