X6 Series - Corrosion Mapping for large surface and piping, X6A-5M128E-0.75x10-SQX5, Frequency: 5 Mhz, Number Elements: 128, Elevation: 10 mm, Element Pitch: 0.75, SONATEST
The SONATEST X6A-5M128E-0.75x10-SQX5 is a high-performance phased array transducer from the renowned X6 Series, specifically engineered for efficient and detailed corrosion mapping on large surfaces and extensive piping systems.
Operating at a center frequency of 5 MHz and featuring a linear array with a significant number of 128 elements, this transducer is designed to generate extensive linear (L-Scans or electronic scans), enabling rapid inspection coverage of substantial areas. The transducer's 10 mm elevation and a precise element pitch of 0.75 mm contribute to high-resolution imaging, which is crucial for the accurate detection and characterization of corrosion, material thinning, and other forms of degradation.
With the capability to utilize an aperture of up to 32 elements, the X6A-5M128E-0.75x10-SQX5 offers excellent defect sizing capabilities, effective material penetration, and a high signal-to-noise ratio, ensuring reliable data acquisition over large areas. The SQX5 designation indicates a secure and rapid Quick I-PEX (QX) connector and an extended 5-meter cable length, providing a dependable connection to compatible SONATEST phased array instruments and increased reach for inspecting large-scale assets and complex geometries.
Key Selling Points:
Optimized for Extensive Corrosion Mapping: Designed for efficient and comprehensive inspection of large surfaces and lengthy piping.
5 MHz Frequency for Balanced Resolution and Penetration: Provides excellent detail for detecting corrosion features across a range of depths.
128 Elements for Wide Electronic Scanning: Enables rapid coverage of significant inspection areas.
Fine 0.75 mm Element Pitch for High-Resolution Imaging: Crucial for accurate defect detection and precise sizing.
Large Aperture Capability (up to 32 Elements): Offers superior defect characterization and material penetration for comprehensive analysis.
Reliable Quick I-PEX (QX) Connector: Ensures fast and secure connection to instruments for uninterrupted operation.
Extended 5-Meter Cable Length: Provides increased reach and flexibility for inspecting large or complex structures.
Part of the Trusted SONATEST X6 Series: Known for high quality and performance in advanced phased array UT.
Benefits:
Maximize Inspection Efficiency on Large Assets: Quickly and effectively map corrosion over extensive areas, saving time and resources.
Achieve Accurate Defect Characterization: High-resolution imaging allows for precise detection and sizing of corrosion, leading to informed maintenance decisions.
Enhance Data Acquisition Speed Over Large Areas: Phased array technology enables rapid electronic scanning, significantly reducing inspection time.
Ensure Reliable Connections Over Distance: Quick I-PEX connector provides a secure and efficient interface, even with the extended cable.
Increase Versatility for Large Structure Inspections: The extended cable provides greater access to hard-to-reach areas on large assets.
Applications:
The SONATEST X6A-5M128E-0.75x10-SQX5 phased array transducer is an ideal solution for comprehensive corrosion mapping on large-scale assets in various industries, including:
Oil and Gas: Inspection of extensive pipelines, large pressure vessels, and vast storage tank farms.
Chemical Processing: Assessment of corrosion in extensive process piping networks and large containment structures.
Infrastructure: Evaluation of corrosion in large bridges, extensive structural supports, and other large-scale constructions.
Marine: Inspection of large ship hulls and expansive offshore platforms for comprehensive corrosion damage assessment.
Power Generation: Corrosion mapping of large storage tanks, lengthy piping systems, and other extensive components in power plants.
The SONATEST X6A-5M128E-0.75x10-SQX5 phased array transducer delivers a powerful and efficient means of conducting comprehensive corrosion mapping on large surfaces and piping, providing high resolution, rapid scanning capabilities, extended reach, and the trusted performance of the SONATEST X6 Series for demanding inspection tasks.
