NM01MINIAB518718745

This CNDT Miniature Angle Beam Transducer is a compact yet powerful ultrasonic transducer designed for precise angle beam inspections in applications with limited access or on small components. Operating at a center frequency of 5 MHz with a small element size of .187" x .187", this transducer provides excellent resolution and sensitivity for detecting small flaws at a refracted shear wave angle of 45 degrees within the test material (typically calibrated for steel; the exact angle may vary slightly depending on the material's acoustic velocity).

The miniature design of this transducer allows for inspections in tight spaces and on components with complex geometries where larger probes might not fit. The 45-degree angle is a commonly used refraction angle for detecting various types of subsurface discontinuities, including cracks and incomplete fusion, depending on their orientation relative to the sound beam.

Equipped with a microdot connector, this transducer offers a secure and reliable connection to compatible ultrasonic flaw detectors, particularly smaller, portable units often used in field inspections. The robust construction ensures durability for demanding NDT environments.

Key Selling Points:

• Miniature Size: Ideal for inspections in confined spaces and on small components.

• Precise 45-Degree Angle Beam: A standard angle for detecting various subsurface flaws.

• Optimal 5 MHz Frequency: Provides a good balance of resolution and penetration for smaller components.

• Small .187" x .187" Element: Enhances resolution for detecting small discontinuities.

• Microdot Connector: Ensures a secure connection to compatible flaw detectors.

• Durable Construction: Built to withstand demanding inspection environments.

• Reliable CNDT Quality: Ensures consistent and dependable performance.

Benefits:

• Enhanced Inspection Capabilities in Limited Access Areas: Enables testing where larger transducers cannot be used.

• Accurate Detection of Small Flaws: High frequency and small element size provide excellent resolution.

• Versatile Application: Suitable for a range of materials and component geometries.

• Reliable Performance: CNDT is a trusted manufacturer of ultrasonic transducers.

• Easy Integration: Microdot connector ensures compatibility with various flaw detectors.

Applications:

This miniature angle beam transducer is commonly used for:

• Inspection of small diameter tubing and pipes.

• Weld inspection in tight or restricted areas.

• Examination of complex geometric components.

• Detection of small cracks and inclusions in various materials.

• Aerospace inspections.

• Automotive component testing.

The CNDT Miniature Angle Beam Transducer, 5 MHz, .187" x .187", 45 Degrees, Microdot Connector is a valuable tool for NDT professionals requiring high resolution and access in confined spaces for angle beam inspections. Its compact design and reliable performance make it ideal for detailed examinations on smaller components and in challenging inspection environments.
