NM01PHS066C

The JIREH Corrosion Thickness Probe Holder Receptacle and Wear Plate is a specialized accessory designed to facilitate accurate and consistent ultrasonic thickness measurements, particularly in applications involving curved surfaces and corrosion assessment. This component serves as a crucial interface for securely holding an ultrasonic thickness gauge probe and ensuring optimal contact with the inspection surface.

The key features of this product are:

• Probe Holder Receptacle: This is the primary component designed to securely house the ultrasonic thickness gauge probe. The specified 19 mm (0.75 in) receptacle diameter indicates the size of the opening intended to accommodate probes with a corresponding diameter. This ensures a snug and stable fit, preventing unwanted movement or loss of contact during measurements.

• Wear Plate: Integrated with the probe holder is a wear plate. This plate is the part of the assembly that directly contacts the inspection surface. Its purpose is to protect the probe and the probe holder from wear and tear caused by repeated scanning or contact with potentially rough or corroded surfaces.

• Curved Design: The most significant feature of this specific model is its curved wear plate. This design is specifically intended for use on cylindrical or other curved surfaces, allowing for consistent and full contact of the probe face with the inspection area. The curvature helps to maintain proper acoustic coupling and ensures accurate thickness readings even when working on non-flat geometries. The specific radius of curvature is not provided in the description and would likely be detailed in the manufacturer's specifications.

Manufactured by JIREH, a reputable provider of remote inspection technologies and NDT accessories, this Corrosion Thickness Probe Holder Receptacle and Wear Plate is likely constructed from durable materials designed to withstand the rigors of industrial environments. The curved wear plate is likely made from a low-friction, wear-resistant material to ensure smooth movement and longevity.

Key Features:

• Secure Probe Holding: 19 mm (0.75 in) receptacle diameter ensures a stable fit for compatible ultrasonic thickness gauge probes.

• Curved Wear Plate: Specifically designed for optimal contact and accurate measurements on curved surfaces.

• Protective Wear Plate: Shields the probe and holder from wear and tear during inspections.

• Durable Construction: Likely made from robust materials for industrial use.

• Manufactured by JIREH: A trusted name in NDT accessories.

• Enhances Measurement Accuracy: Ensures consistent probe contact and coupling on curved surfaces.

Applications:

• Ultrasonic thickness gauging on pipes, tubes, and other cylindrical structures.

• Corrosion surveys and monitoring on curved surfaces.

• Thickness measurements on tanks and vessels with curved walls.

• Any application requiring accurate ultrasonic thickness readings on non-flat geometries.
