NM01S112544T

ADELIX S112-5-4x4T High-Temperature UT Transducer

This is a specialized, single-element ultrasonic transducer engineered for precision inspection in extreme environments. Designed by ADELIX, this high-performance probe allows for direct, real-time ultrasonic testing on surfaces with elevated temperatures, eliminating the need for costly and time-consuming component cool-down.

Key Features & Benefits

• Extreme High-Temperature Performance: Built with advanced materials, this transducer is rated for continuous use on surfaces up to 400°C (752°F). This capability is invaluable for industries such as power generation, oil & gas, and metallurgy, allowing for in-service inspections and reducing downtime.

• Precision & Resolution: The 5 MHz frequency and 4x4mm element provide a powerful combination of high resolution and a small acoustic footprint. This allows you to detect minute flaws and anomalies while easily accessing tight inspection areas and complex geometries.

• Robust Construction: The transducer's body is designed to withstand the rigors of industrial environments. Its durable construction ensures a long service life and reliable performance in demanding conditions.

• Direct-Contact Inspection: As a straight-beam (longitudinal wave) contact probe, it delivers a direct sound path into the material, making it ideal for accurate thickness measurement, lamination detection, and general flaw scanning.

Ideal For

• High-temperature weld inspection

• Corrosion monitoring in hot piping

• Flaw detection in power plant boilers and furnaces

• In-service inspection of components in the oil & gas industry

Technical Specifications

• Manufacturer: ADELIX

• Model: S112-5-4x4T

• Probe Type: Single Element, Contact

• Frequency: 5 MHz

• Element Size: 4mm x 4mm

• High-Temperature Rating: Up to 400°C (752°F)

• Wave Type: Longitudinal (Straight Beam)
