NM01L1086
UVG3 2.0 Midlight has an intensity at the center of ≈ 9,000 μw/cm2, generating a beam profile of approximately 3.8 inches / 9.5 cm, and is in compliance with ASTM E3022-18, Pratt and Whitney and USAF requirements. Labino SKU: L1086
Choose Quantity
Labino — UVG3 2.0 Midlight UV-A LED Inspection Lamp
High-Intensity UV-A Lamp for Fluorescent NDT Inspection SKU: L1086Overview
The Labino UVG3 2.0 Midlight is a professional UV-A LED inspection lamp designed for fluorescent non-destructive testing applications. With an intensity of approximately 9,000 µW/cm² at the center, this lamp provides strong UV-A output for detecting fluorescent indications during magnetic particle inspection and liquid penetrant inspection.
Generating a beam profile of approximately 3.8" / 9.5 cm, the UVG3 2.0 Midlight offers focused and reliable illumination for detailed inspection work. Its high-intensity output supports clear indication visibility while maintaining a practical beam size for controlled inspection areas.
Built in compliance with ASTM E3022-18, Pratt & Whitney, and USAF requirements, this lamp is ideal for aerospace, manufacturing, maintenance, and critical NDT environments where reliable UV-A performance and inspection compliance are essential.
What's Included
| Item | Details |
|---|---|
| UV-A Lamp | UVG3 2.0 Midlight inspection lamp |
| Documentation | User manual / compliance documentation, if included |
Box Dimensions & Shipping Weight (Estimated)
| Parameter | Imperial |
|---|---|
| Length | 12.0 in |
| Width | 8.0 in |
| Height | 5.0 in |
| Dimensions (L × W × H) | 12.0 × 8.0 × 5.0 in |
| Weight | 3.0 lb |
Key Specifications
| Parameter | Details |
|---|---|
| Product Type | UV-A LED inspection lamp |
| Model | UVG3 2.0 Midlight |
| UV-A Intensity | ≈ 9,000 µW/cm² at center |
| Beam Profile | Approx. 3.8" / 9.5 cm |
| Compliance | ASTM E3022-18, Pratt & Whitney, USAF requirements |
| Application | Fluorescent NDT inspection |
| Manufacturer | Labino |
| SKU | L1086 |
Performance Features
High-Intensity UV-A Output
Delivers approximately 9,000 µW/cm² at the beam center for strong fluorescent indication visibility.
Focused Beam Profile
Approximately 3.8" / 9.5 cm beam profile supports detailed inspection of controlled areas.
Inspection Compliance Support
Designed to comply with ASTM E3022-18, Pratt & Whitney, and USAF requirements.
Reliable Fluorescent NDT Performance
Supports accurate MPI and LPI inspection workflows in critical environments.
User-Friendly Design
- Practical beam size for focused inspections
- Strong UV-A output for clear indication detection
- Suitable for field, shop, and laboratory use
- Designed for efficient fluorescent inspection workflows
Built for Industrial Environments
- Durable construction for professional NDT use
- Reliable performance in aerospace and manufacturing inspection programs
- Suitable for routine and critical inspections
- Designed for demanding fluorescent NDT applications
Compatibility
Compatible with:
- Fluorescent magnetic particle inspection workflows
- Fluorescent liquid penetrant inspection workflows
- ASTM E3022-18 inspection requirements
- Aerospace and defense inspection programs
- UV-A compliant NDT procedures
Ideal Applications
- Fluorescent magnetic particle inspection
- Liquid penetrant inspection
- Aerospace component inspection
- Pratt & Whitney and USAF inspection programs
- Manufacturing QA/QC
- Maintenance and repair operations
- Critical fluorescent NDT inspections
About Labino
Labino is a global leader in UV and white light inspection equipment, providing high-performance lamps, meters, sensors, and accessories for non-destructive testing. Their products are trusted worldwide for reliability, compliance, and professional inspection performance.
