Labino BB Helios DUO Power – Handheld UV-A LED Inspection Lamp
SKU: L1037 | NOMO SKU: NM01L1037
A professional handheld UV-A LED inspection lamp featuring dual battery and mains power operation, nine high-performance LEDs, approximately 8,500 µW/cm² initial UV-A intensity at 15 inches, and a wide 275 mm (10.8-inch) inspection beam. Designed for fluorescent magnetic particle inspection and liquid penetrant testing.

| 8,500µW/cm² at 15 inches | 9 LEDsUV-A light sources | 275 mmInspection beam diameter | DUOBattery and mains power |
The Labino BB Helios DUO Power is a professional handheld ultraviolet inspection lamp designed for non-destructive testing applications requiring high UV-A intensity and a large, uniform inspection beam.
The BB Helios utilizes nine UV-A LEDs with a nominal peak wavelength of 365 nm. The Midlight configuration produces approximately 8,500 µW/cm² initial irradiance at a working distance of 38 cm (15 inches), providing effective illumination for identifying fluorescent inspection indications.
A 275 mm (10.8-inch) diameter beam, measured above 1,200 µW/cm² at 15 inches, provides wide inspection coverage. The optical system distributes ultraviolet light uniformly across the working area, minimizing visible LED footprints, shadows and irregular beam patterns.
The DUO configuration combines battery-powered portability with the option to operate from an external mains power supply. This flexibility makes the lamp suitable for field inspections, workshop environments, manufacturing facilities and stationary magnetic particle inspection benches.
Designed and manufactured in Sweden, the BB Helios features an ergonomic pistol-grip housing, integrated UV-A LEDs, a white-light blocking filter, instant-on operation and a regulated power system that helps maintain consistent illumination as battery charge decreases.
Product Photography
![]() Original BB Helios DUO handheld lamp | ![]() Labino BB Helios family reference image |
Key Features
![]() | High-intensity UV-A performanceNine high-performance ultraviolet LEDs deliver approximately 8,500 µW/cm² initial intensity at 38 cm (15 inches). The high-output Midlight beam helps reveal fluorescent indications during professional NDT examinations. |
DUO battery and mains operation
The DUO power system allows portable battery operation or connection to an external mains supply. The lamp can operate from mains power while its internal battery is charging, providing flexibility between field and stationary inspection work.
Wide and uniform UV-A beam
The Midlight configuration provides a 275 mm (10.8-inch) diameter inspection beam above 1,200 µW/cm² at 38 cm. Its optical design delivers a homogeneous illumination pattern that minimizes shadows, dark spots and individual LED footprints.
365 nm UV-A wavelength
The LEDs emit ultraviolet radiation with a peak wavelength of approximately 365 nm, suitable for excitation of fluorescent inspection materials used in penetrant and magnetic particle testing.
Instant-on illumination
The LED light source reaches full operating output immediately after switching on, eliminating the warm-up period associated with traditional mercury-vapor UV inspection lamps.
White-light blocking filter
An integrated optical filter minimizes visible light emission while allowing UV-A illumination to pass through, improving the visibility of fluorescent indications in controlled inspection environments.
Regulated UV output
A current regulation system helps maintain stable UV-A output as the battery discharges, supporting consistent illumination during inspection sessions.
Durable industrial housing
The original BB Series uses anodized aluminum and reinforced plastic components with an ergonomic pistol-grip handle. Its IP65-rated enclosure provides protection against dust and water jets under specified conditions.
Professional inspection standards
The original BB Helios has been documented as meeting ASTM E3022-15 and ISO 3059:2012. Suitability for any additional aerospace or customer-specific specification should be confirmed against the exact model and inspection procedure.
DUO Power System
| Battery Operation | Mains Operation |
|---|---|
| The integrated rechargeable lithium-ion battery provides portable UV-A inspection capability without requiring a continuous power connection. | The external power supply enables operation from a compatible electrical outlet while charging the battery, supporting extended inspection sessions. |
| 14.8 V lithium-ion battery | 100–240 V AC charger input |
Specifications
| General | |
| Manufacturer | Labino AB |
|---|---|
| Model | BB Helios DUO Power – Midlight |
| Manufacturer SKU | L1037 |
| NOMO SKU | NM01L1037 |
| Product Series | Original BB Series – BigBeam Helios |
| Product Type | Handheld UV-A LED inspection lamp |
| Manufacturing Origin | Sweden |
| Weight with Battery | 1.7 kg (3.74 lb) |
| UV-A Optical Performance | |
| UV-A LED Quantity | 9 |
| Peak Wavelength | 365 nm |
| Initial UV-A Intensity | Approximately 8,500 µW/cm² at 38 cm (15 in) |
| Beam Diameter Above 1,200 µW/cm² | 275 mm (10.8 in) at 38 cm |
| Visible Light Emission | Approximately 1 lux / 0.09 fc |
| UV-B Emission | Manufacturer describes the LED source as UV-B-free |
| Startup | Instant-on |
| Optical Filter | White-light blocking filter |
| Nominal LED Service Life | 30,000 hours, manufacturer estimate |
| Power and Battery | |
| Power Configuration | DUO – Battery and mains |
| Battery Type | Rechargeable lithium-ion |
| Battery Voltage | 14.8 V |
| Battery Runtime | Approximately 2.5–3.5 hours depending on the documented configuration and operating conditions; confirm for the supplied unit |
| Charger Input | 100–240 V AC |
| Charging Time, Lamp Off | Approximately 1 hour 20 minutes, per original DUO technical sheet |
| Simultaneous Charging and Operation | Supported with compatible charger |
| Physical Characteristics | |
| Housing Diameter | Approximately 140 mm (5.5 in) |
| Housing Material | Anodized aluminum and reinforced PA6-30 plastic |
| Handle | Ergonomic pistol grip |
| Ingress Protection | IP65, original BB Series |
| Product Dimensions (L × W × H) | Complete external dimensions not independently verified |
| Estimated Box Dimensions (L × W × H) | 16 × 12 × 8 in (406 × 305 × 203 mm), provisional estimate |
| Estimated Shipping Weight | 7 lb (3.18 kg), provisional estimate |
| Inspection Standards | |
| ASTM | ASTM E3022-15, original model documentation |
| ISO | ISO 3059:2012 |
| Additional Customer Specifications | Confirm against original model documentation and applicable customer requirements |
Specifications apply to the original BB Helios DUO L1037, not the newer BB 2.0 Helios L1077. Battery runtime differs among original manufacturer and distributor documents. Shipping dimensions and weight are provisional estimates and must be confirmed before freight quotations.
What's in the Box
- 1 × Labino BB Helios DUO UV-A LED inspection lamp
- Integrated rechargeable lithium-ion battery
- Compatible external charging power supply
- AC power cord
- UV-blocking protective goggles, subject to supplied kit configuration
The original BB Helios DUO was sold in different configurations. Confirm the included charger, protective eyewear, carrying accessories and power cable with NOMO NDT before ordering.
Applications
| ✓ Fluorescent magnetic particle inspection (MPI/MT) | ✓ Fluorescent penetrant inspection (FPI/PT) |
| ✓ Aerospace component inspection | ✓ Automotive manufacturing |
| ✓ Weld and fabrication inspection | ✓ Industrial quality assurance |
| ✓ Magnetic particle inspection benches | ✓ Field maintenance inspection |
| ✓ Fluorescent material examination | ✓ Industrial NDT laboratories |
Operation and Handling
UV-A intensity verification
Verify ultraviolet irradiance using a calibrated UV-A radiometer at the required working distance before inspection. Confirm that the measured output meets the applicable inspection procedure.
Battery charging and operation
Use only compatible Labino charging equipment. Verify electrical compatibility before connecting the charger, and follow the battery handling instructions for the original DUO model.
UV protective eyewear
Wear appropriate UV-blocking protective eyewear. Avoid directing the UV-A source toward the eyes or exposed skin and follow applicable ultraviolet radiation safety procedures.
Optical filter maintenance
Keep the front optical filter clean and free of scratches, cracks or chemical deposits. Do not use the lamp with a damaged or missing protective filter.
Model identification
When purchasing replacement batteries, chargers or accessories, identify the exact Labino BB Helios DUO model and part number L1037. Accessories for the newer BB 2.0 Series are not automatically interchangeable.
Downloads
| ⬇ BB Helios DUO Midlight Technical Datasheet (PDF) |
| ⬇ Labino Original BB Series Catalog (PDF) |
| ⬇ Labino BB Series Specifications and Compliance (PDF) |
About Labino
Labino AB is a Swedish manufacturer specializing in professional ultraviolet inspection lighting for non-destructive testing and industrial applications. The company develops UV-A equipment used in aerospace, automotive, manufacturing, transportation and other industries requiring fluorescent inspection methods.
Labino's product portfolio includes handheld UV-A LED lamps, flashlights, overhead inspection lighting, explosion-protected inspection systems and ultraviolet measurement equipment. The original BigBeam Helios family helped establish the company's large-beam handheld inspection lighting range.
