NM01DA200S
The PARKER DA-200S AC/DC Magnetic Yoke (230 V) is a rugged, high-performance instrument designed for magnetic particle inspection (MPI) according to accepted non-destructive testing standards. This versatile yoke allows inspectors to quickly and reliably locate surface and some sub-surface flaws in ferromagnetic materials.
Operating on a 230 V, 50/60 Hz power supply with a current draw of 4 Amps, the DA-200S offers the flexibility to switch between constant AC (Alternating Current) and half-wave rectified DC (Direct Current) fields with a simple flip of a switch. AC is ideal for detecting surface-breaking defects, while DC can reveal some sub-surface flaws. The yoke can be used with dry powder, wet visible, or wet fluorescent magnetic particle techniques.
The DA-200S features a high-impact, glass-filled nylon housing for durability in demanding environments. It comes with a 10-foot (3-meter), 3-wire power cord for convenient operation. The yoke has a pole spacing that can be adjusted up to 18 inches (457 mm). It is designed for a duty cycle of 2 minutes on - 2 minutes off to prevent overheating.
Key Features:
AC and DC Operation: Versatile for locating both surface and some sub-surface defects.
230 V Operation: Compatible with standard 230 V power supplies.
Rugged Construction: High-impact, glass-filled nylon housing for durability.
Adjustable Pole Spacing: Accommodates various inspection requirements (0 - 18 inches).
Exceeds ASTM Lift Test Standards: Ensures reliable magnetic field strength.
CE Certified (Optional): 230V model available with CE certification.
One-Year Repair/Replacement Guarantee: Provides peace of mind.
Benefits for Selling Purposes:
Versatile Flaw Detection: Detect both surface and near-surface flaws with AC/DC operation.
Reliable Performance: Meets and exceeds industry standards for magnetic particle inspection.
Durable for Field Use: Rugged construction withstands demanding environments.
Easy to Use: Simple switching between AC and DC fields.
Wide Application Range: Suitable for various MPI techniques and inspection needs.
Ensures Compliance: Helps meet quality and safety standards.
Applications:
Inspection of welds.
In-service inspections.
Spot inspections.
Field testing.
Demanding environments.
Detecting defects such as inclusions, seams, welding slag, quenching cracks, and fatigue cracks.
