NM01T2024001
Dual Element Transducers 10.0 MHz, 1/4", Microdot Top Connector, Dakota NDT SKU: T-202-4001
Choose Quantity
Dakota NDT — Dual Element Transducer (10 MHz, 1/4", Microdot Top Connector)
High-Resolution UT Probe for Precision Thickness & Corrosion Measurement SKU: T-202-4001Overview
The Dakota NDT Dual Element Transducer is a compact ultrasonic probe designed for precision thickness measurement and corrosion inspection applications. Operating at 10 MHz with a 1/4" diameter element, this probe provides high-resolution performance for detecting small thickness variations, thin-wall conditions, and localized corrosion.
Its dual element design uses separate transmit and receive elements to reduce dead zone and improve near-surface measurement capability. This makes it especially useful for applications requiring accurate readings on thin materials, small components, and detailed inspection areas.
Equipped with a Microdot top connector, the transducer supports secure signal transmission and straightforward cable routing during field, shop, and laboratory inspection workflows.
What's Included
| Item | Details |
|---|---|
| UT Transducer | Dual element probe, 10 MHz, 1/4", Microdot top connector |
Box Dimensions & Shipping Weight (Estimated)
| Parameter | Imperial |
|---|---|
| Length | 6.0 in |
| Width | 4.0 in |
| Height | 3.0 in |
| Dimensions (L × W × H) | 6.0 × 4.0 × 3.0 in |
| Weight | 0.5 lb |
Key Specifications
| Parameter | Details |
|---|---|
| Probe Type | Dual element ultrasonic transducer |
| Frequency | 10 MHz |
| Element Diameter | 1/4" |
| Connector Type | Microdot |
| Connector Location | Top |
| Application | Thickness measurement & corrosion inspection |
| Manufacturer | Dakota NDT |
| SKU | T-202-4001 |
Performance Features
High-Resolution 10 MHz Frequency
Provides excellent sensitivity for thin materials and small thickness changes.
Compact 1/4" Element Size
Ideal for localized inspection areas, small components, and restricted access points.
Dual Element Design
Improves near-surface resolution and supports reliable corrosion measurements.
Microdot Top Connector
Provides secure signal connection with convenient cable routing from the top of the probe.
User-Friendly Design
- Compact probe size for precise placement
- Top connector configuration for straightforward setup
- Lightweight and easy to handle
- Designed for efficient inspection workflows
Built for Industrial Environments
- Durable construction for repeated inspection use
- Reliable performance in field and maintenance conditions
- Suitable for precision thickness measurements
- Designed for professional NDT workflows
Compatibility
Compatible with:
- Ultrasonic thickness gauges
- Ultrasonic flaw detectors
- Dual element UT cable setups
- Microdot cable connections
- Corrosion monitoring workflows
Ideal Applications
- Precision thickness measurement
- Thin-wall material inspection
- Localized corrosion monitoring
- Small component testing
- Manufacturing and maintenance QA/QC
- Pipeline, tank, and vessel inspection
About Dakota NDT
Dakota NDT is a trusted manufacturer of ultrasonic testing equipment and accessories, providing reliable probes, gauges, wedges, and flaw detection solutions for professional NDT applications. Their products are widely used where accuracy, durability, and consistent inspection performance are essential.
