Labino — Apollo 2.0 UV-A Radiometer / Photometer Double Kit
Wireless UV-A & Visible Light Meter with Two Sensors, NIST Traceability and ISO/IEC 17025 Calibration
SKU: M514
Overview
The Labino Apollo 2.0 is a professional radiometer/photometer designed for accurate measurement of UV-A irradiance and visible light during fluorescent NDT inspections.
The Double Kit includes one reader and two wireless sensor units, allowing inspectors to measure UV-A and visible light without cables. Data is transmitted wirelessly via Bluetooth at distances up to approximately 5 m (16 ft).
The Apollo 2.0 features automatic ranging, simultaneous UV-A and visible-light measurement, Hold and Peak functions, and calibration traceable to NIST.
What's Included
| Item | Quantity |
|---|---|
| Apollo Reader Unit | 1 |
| Wireless UV-A / Visible Light Sensors | 2 |
| Calibration Certificate | 1 |
| Carrying Case | 1 |
| Calibration | ISO/IEC 17025 |
| Manufacturer | Labino |
| SKU | M514 |
Key Features
Measures UV-A irradiance and visible illumination
Two wireless sensor units
Wireless measurement up to 5 m (16 ft)
Bluetooth data transmission
Simultaneous UV-A and visible-light measurement
Automatic ranging
Hold function for retaining current measurements
Peak function for recording maximum measurements
Traceable to NIST
ISO/IEC 17025 calibration
Compact and lightweight design
Ideal for fluorescent MPI and penetrant inspection
Specifications
| Parameter | Details |
|---|---|
| Product Type | UV-A Radiometer / Photometer |
| Model | Apollo 2.0 Double Kit |
| UV-A Measurement Range | 0–50,000 µW/cm² |
| UV-A Spectral Range | 300–400 nm |
| UV-A Accuracy | ±4% |
| Visible Light Range | 0–10,000 Lux |
| Visible Light Range | 0–1,000 fc |
| Visible Light Spectral Range | 400–700 nm |
| Visible Light Accuracy | ±3% |
| Wireless Connection | Bluetooth |
| Wireless Distance | Up to 5 m / 16 ft |
| Sensor Units | 2 |
| NIST Traceability | Yes |
| Calibration | ISO/IEC 17025 |
| Manufacturer | Labino |
| SKU | M514 |
Double Sensor Advantage
The two-sensor configuration provides additional flexibility for inspection and calibration programs.
A second sensor can help reduce downtime when one sensor is being recalibrated and allows the same reader to be used with multiple calibrated sensor units.
Ideal Applications
Fluorescent Magnetic Particle Inspection (MPI)
Fluorescent Penetrant Inspection (FPI/LPI)
UV-A lamp verification
Visible-light measurement
NDT inspection stations
Aerospace inspection
Manufacturing QA/QC
Calibration and verification programs
Field NDT applications
Box Dimensions & Shipping Weight
| Parameter | Estimated |
|---|---|
| Box Dimensions (L × W × H) | 14 × 10 × 5 in |
| Shipping Weight | 3.5 lb |
Note: Box dimensions and shipping weight are estimated for inventory and shipping purposes.
About Labino
Labino manufactures professional UV-A inspection lights, radiometers, photometers, and measurement equipment for fluorescent penetrant and magnetic particle inspection across aerospace, manufacturing, oil & gas, automotive, and industrial NDT applications.
