Dakota NDT — PSS50105 Standard Shear Wave Transducer (5 MHz, 0.5" × 1.0", Composite)
Angle Beam UT Probe with AWS Calibration Capability SKU: PSS50105Overview
The Dakota NDT PSS50105 Standard Shear Wave Transducer is a high-performance ultrasonic probe designed for angle beam inspections and weld evaluation. Operating at 5 MHz with a 0.5" × 1.0" rectangular element, this transducer provides excellent resolution and enhanced beam coverage for detecting small discontinuities across wider inspection areas.
Constructed with a durable composite face, this probe offers extended wear resistance and consistent performance in demanding inspection environments. Designed for use with shear wave wedges, it enables precise angled beam inspections for identifying defects such as cracks, lack of fusion, and inclusions.
With AWS compatibility, the PSS50105 supports calibration and inspection procedures in accordance with industry standards. The BNC connector ensures reliable signal transmission and compatibility with a wide range of ultrasonic flaw detectors.
What's Included
| Item | Details |
|---|---|
| UT Transducer | PSS50105 shear wave probe, 5 MHz, 0.5" × 1.0" |
Box Dimensions & Shipping Weight (Estimated)
| Parameter | Imperial |
|---|---|
| Length | 6.0 in |
| Width | 4.0 in |
| Height | 3.0 in |
| Dimensions (L × W × H) | 6.0 × 4.0 × 3.0 in |
| Weight | 0.8 lb |
Key Specifications
| Parameter | Details |
|---|---|
| Probe Type | Shear wave ultrasonic transducer |
| Model | PSS50105 |
| Frequency | 5 MHz |
| Element Size | 0.5" × 1.0" |
| Face Material | Composite |
| Connector Type | BNC |
| Calibration | AWS compatible |
| Application | Angle beam ultrasonic testing |
Performance Features
High-Resolution Inspection (5 MHz)
Provides excellent sensitivity for detecting small and critical defects.
Extended Element Coverage
Rectangular 0.5" × 1.0" element improves scanning efficiency over larger areas.
Composite Wear Face
Enhances durability and extends probe life in demanding conditions.
AWS Calibration Support
Enables compliance with AWS inspection standards.
User-Friendly Design
- Easy connection to UT instruments
- Stable mounting with compatible wedges
- Durable and wear-resistant face
- Designed for efficient inspection workflows
Built for Industrial Environments
- Rugged construction for heavy-duty use
- Suitable for field and shop inspections
- Reliable performance in continuous operation
- Designed for professional NDT applications
Compatibility
Compatible with:
- Dakota NDT wedges (angle beam setups)
- Ultrasonic flaw detectors
- BNC UT cables
- AWS-based inspection procedures
Ideal Applications
- Weld inspection and flaw detection
- Structural steel inspection
- Pipeline and pressure vessel inspection
- Oil & gas and construction industries
- Fabrication and manufacturing QA/QC
- Large-area angle beam ultrasonic testing (UT)
