NM01FG3321
Mi-Glow 418 from Circle Systems is a high-performance, water-based fluorescent magnetic particle inspection (MPI) powder, conveniently packaged in a 2 lb. jar. This advanced product utilizes the latest generation Mi-Glow 800 and Mi-Glow 920 particles, renowned for their exceptional sensitivity, uniform size, and ideal magnetic characteristics.
Specifically formulated for use in water media, Mi-Glow 418 is premixed with a borate-free Wetting Agent #34. This innovative wetting agent offers excellent wetting characteristics, superior, long-term corrosion inhibition for steel and cast iron, and incomparable defoaming properties, ensuring a reliable and efficient MPI process. The borate-free formulation also helps to alleviate potential health and safety concerns associated with borate-containing chemistries.
Mi-Glow 418 exhibits high fluorescence, producing bright yellow-green indications under UV-A light, making it ideal for detecting fine to large discontinuities in critical components such as forgings, castings, welds, and other high-volume applications. Its low foaming and minimal background fluorescence contribute to clear and easily interpretable indications, even on components with surface irregularities. The consistent particle size further enhances sensitivity and resolution.
Notably, Mi-Glow 418 can be effectively used in darkened inspection areas as well as in dual response environments utilizing a combination of visible and UV-A light, offering versatility for various inspection setups. Circle Systems' unique bonding method ensures total particle encapsulation, eliminating free unbonded pigment and resulting in a high-performing MPI powder with low background noise.
Key Selling Points:
High Sensitivity: Utilizes advanced Mi-Glow 800 and 920 particles for exceptional flaw detection.
Water-Based Convenience: Premixed with a borate-free wetting agent for easy use in water media.
Superior Performance: High fluorescence, low foaming, and minimal background for clear indications.
Excellent Corrosion Inhibition: Provides long-term protection for steel and cast iron.
Versatile Lighting Compatibility: Effective in both darkened and dual response inspection environments.
Economical Usage: Requires less product concentration compared to some competitors.
Meets Industry Standards: Complies with relevant specifications including ASTM E 709, ASTM E 1444, AMS 3044, and more (depending on lighting conditions).
Benefits:
Enhanced Flaw Detection: Reliably identify a wide range of surface and near-surface discontinuities.
Improved Inspection Efficiency: Easy preparation and application in water-based systems.
Clear and Accurate Results: High fluorescence and low background ensure easy interpretation.
Protects Inspected Parts: Borate-free wetting agent inhibits corrosion.
Adaptable to Various Inspection Setups: Can be used under different lighting conditions.
Cost-Effective Solution: Lower consumption rate reduces overall inspection costs.
Applications:
Mi-Glow 418 is ideal for the fluorescent magnetic particle inspection of:
Forgings and Castings
Welds
High-Volume Automotive Components
Oil and Gas Tubular Goods (OCTG)
General Metal Fabrications
Components where post-heat treatment MPI is required (can withstand temperatures up to 300°F/149°C intermittently)
The Mi-Glow 418 Water-Based Fluorescent Particles in a convenient 2 lb. jar provide a high-performance, reliable, and cost-effective solution for your critical magnetic particle inspection needs, ensuring accurate flaw detection and contributing to the safety and quality of your inspected components.
