The UT Adaptor, part number MC-00SZ1250BNC-F and manufactured by MC, is a passive interconnect device specifically engineered for use in ultrasonic testing (UT) applications. This adapter provides a reliable and direct connection between components or cables that are equipped with differing connector interfaces: a LEMO 00 female connector and a BNC female connector.

Key Features:

• Connector Interface Conversion: This adapter is designed to seamlessly link a LEMO 00 male connector (found on various UT probes, instruments, and cables) with a BNC male connector (also commonly used in UT and general electronic setups).

• LEMO 00 Female Port: One end of the adapter features a high-quality LEMO 00 series female receptacle. This connector type is characterized by its compact design, secure push-pull locking mechanism, and excellent signal integrity, ensuring a stable and dependable connection with mating LEMO 00 male connectors.

• BNC Female Port: The opposing end of the adapter is equipped with a standard BNC female receptacle. BNC connectors are widely utilized for coaxial cables in a broad range of applications, including radio frequency (RF) and numerous ultrasonic testing instruments, providing a quick and reliable bayonet-style connection with BNC male plugs.

• Passive Signal Transmission: This adapter operates as a passive component, meaning it does not actively modify, amplify, or otherwise alter the ultrasonic signal passing through it. Its sole function is to establish a conductive pathway between the connected interfaces, preserving the integrity of the transmitted signal.

• Specific Part Number Designation: The unique part number MC-00SZ1250BNC-F, assigned by the manufacturer MC, likely denotes specific attributes of this particular adapter. These could include the materials of construction, the internal wiring configuration, the impedance matching characteristics, or other performance specifications. For the most accurate and detailed technical information, consulting the official datasheet provided by MC for this specific part number is recommended.

• Quality Manufacturing: As a product of MC, this adapter is expected to be manufactured to high-quality standards, ensuring durability and reliable performance in demanding ultrasonic testing environments.

Applications in Ultrasonic Testing:

• Facilitating the connection of an ultrasonic probe or cable terminated with a LEMO 00 male connector to an ultrasonic instrument or another cable featuring a BNC male connector.

• Enabling the interchangeability and use of various ultrasonic testing accessories or equipment that utilize different connector types within a testing setup.

• Providing a necessary interface when integrating components from different ultrasonic testing systems that adhere to either LEMO 00 or BNC connector standards.

• Offering a practical solution for overcoming connector incompatibility issues in diverse ultrasonic testing configurations.

Importance:

• Ensures Compatibility Across Equipment: This adapter resolves connectivity challenges arising from the use of different connector types in ultrasonic testing.

• Provides a Convenient Interfacing Solution: It offers a straightforward and efficient method for linking incompatible ultrasonic testing components without the need for cable modifications or equipment replacements.

• Maintains Signal Integrity: The passive design is intended to ensure the reliable transmission of ultrasonic signals with minimal degradation.

• Facilitates Versatility in Testing Setups: By bridging connector differences, this adapter enhances the flexibility and adaptability of ultrasonic testing procedures.
