NM01Z1600005

The Dakota MX1-DL Corrosion Thickness Gauge, also known as the MMX-7, is a versatile and robust ultrasonic thickness gauge specifically designed for measuring the thickness of materials affected by corrosion or erosion. This handheld device is ideal for inspections in various industries, providing accurate and reliable measurements even on coated surfaces using its Echo-Echo (Thru-Paint) mode.

The MX1-DL features a clear, 1/8 inch VGA grayscale display that is easy to read in various lighting conditions. Its user-friendly interface and intuitive keypad allow for quick setup and operation. The gauge utilizes dual element transducers (1 to 10 MHz) to ensure accurate readings in challenging applications.

A key feature of the MX1-DL is its time-based B-Scan, which displays a cross-sectional view of the test material, making it excellent for identifying pits and other irregularities. It also boasts a high-speed scan mode that takes up to 250 readings per second, displaying the minimum thickness encountered during the scan. The built-in data logger with 4GB of internal memory allows for the storage of thousands of readings and waveforms for comprehensive data analysis and reporting via the included Windows PC software and USB-C connectivity.

Key Selling Points:

• Versatile Measurement Modes: Pulse-Echo for flaw and pit detection, and Echo-Echo for accurate readings through paint and coatings up to 1mm (40 mils).

• Excellent Corrosion Detection: Time-based B-Scan provides a visual representation of material loss.

• High-Speed Scanning: Captures up to 250 readings per second for efficient inspection.

• Large Data Storage: 4GB internal memory for storing extensive measurement data and waveforms.

• User-Friendly Interface: Easy-to-read grayscale display and intuitive keypad.

• Robust and Durable: Extruded aluminum body with sealed end caps for demanding environments.

• PC Software Included: For easy data transfer, analysis, and reporting.

Benefits:

• Accurate Corrosion Assessment: Provides reliable thickness measurements on corroded materials.

• Efficient Inspections: High-speed scanning and data logging save time and improve productivity.

• Improved Data Analysis: B-Scan and PC software enable comprehensive evaluation of material condition.

• Reduced Coating Removal: Echo-Echo mode allows for measurements without removing paint.

• Durable and Long-Lasting: Rugged construction ensures reliable performance in the field.

Applications:

The Dakota MX1-DL Corrosion Thickness Gauge is ideal for a wide range of industries, including:

• Oil and Gas (pipeline and tank inspection)

• Petrochemical

• Power Generation

• Marine

• Aerospace

• Infrastructure (bridges, storage tanks)

• General manufacturing and maintenance

The Dakota MX1-DL Corrosion Thickness Gauge (MMX-7) is a powerful and reliable tool for professionals needing accurate corrosion assessment and material thickness measurements in various demanding applications. Its advanced features and robust design make it a valuable asset for ensuring structural integrity and safety.
