NM0135610024
The Equotip 550 Leeb D & UCI Hardness Testing System Kit by Proceq offers a comprehensive and versatile solution for portable hardness testing. This kit combines two established hardness testing methods – Leeb rebound and Ultrasonic Contact Impedance (UCI) – providing users with the flexibility to accurately measure the hardness of a wide range of metallic materials in various applications.
This all-in-one kit is designed for on-site testing of heavy, large, or installed parts, as well as smaller components and heat-treated surfaces. The Equotip 550 touchscreen unit features an intuitive interface, interactive wizards, and customizable reporting functions, making hardness testing and data analysis efficient and user-friendly. The rugged housing ensures reliable operation even in demanding industrial environments.
This comprehensive kit consists of:
Equotip 550 Leeb D: The base unit equipped for Leeb rebound hardness testing. The Leeb method is ideal for quick on-site measurements on a wide variety of metals, especially large and heavy components. Calibration is performed according to DIN EN ISO 16859-2, single level, vertical.
Equotip UCI Probe HV1-HV10: This probe utilizes the Ultrasonic Contact Impedance (UCI) method, which is particularly suitable for testing fine-grained materials, thin components, and heat-treated surfaces. The UCI method allows for measurements with different test loads (HV1 to HV10) within a single probe. Calibration is performed according to DIN 50159-2, covering all hardness levels.
Equotip UCI Test Block ~850 HV, ISO 6507-3 HV5 Calibration: A certified test block used for accurate calibration and verification of the UCI probe, ensuring measurements are traceable to ISO 6507-3 HV5 standards.
ISO 17025 Accredited Calibrations: Both the Leeb and UCI testing methods within this kit are supported by ISO 17025 accredited calibrations, providing users with confidence in the accuracy and reliability of their hardness measurements.
Key Selling Points:
2-in-1 Hardness Testing Solution: Combines the versatility of Leeb and the precision of UCI methods in a single kit.
Wide Application Range: Suitable for testing a broad spectrum of materials and component geometries.
Accurate and Traceable Measurements: Calibrated according to relevant ISO and DIN standards with ISO 17025 accreditation.
User-Friendly Touchscreen Interface: Simplifies testing procedures and data analysis.
Portable and Rugged Design: Ideal for on-site testing in demanding industrial environments.
Benefits:
Increased Testing Efficiency: Quickly switch between Leeb and UCI methods depending on the application.
Comprehensive Material Coverage: Accurately measure hardness on a wide variety of metals, including those with complex geometries or surface conditions.
Reliable and Compliant Results: ISO and DIN compliant with accredited calibrations ensure data integrity.
Easy Data Management and Reporting: The Equotip 550 unit offers advanced software features for data analysis and report generation.
Reduced Inspection Costs: A single instrument provides the capabilities of two separate hardness testers.
Applications:
On-site hardness testing of large structures, pipelines, and heavy machinery (Leeb).
Hardness testing of heat-affected zones, welds, and coated materials (UCI).
Testing of thin sheets, small parts, and components with complex shapes (UCI).
Incoming material inspection and quality control.
Verification of heat treatment processes.
Failure analysis and material characterization.
The Equotip 550 Leeb D & UCI Hardness Testing System Kit is a powerful and versatile solution for professionals requiring accurate and reliable portable hardness testing across a diverse range of applications, backed by industry-leading standards and accredited calibrations.
Technical Details:
Display: 7” color capacitive touchscreen
Memory: Internal 8 GB flash memory (>1’000’000 measurements)
Combination with another testing method: UCI, Portable Rockwell (PRT)
Connectivity: Ethernet & USB-B (PC connection), USB-A (PRT), Probe-specific slots
Battery: 3.6V, Li-Ion, 14’000 mAh
Battery lifetime: > 10h (in standard operating mode)
Charging time: < 9h, < 5.5 h (External quick charger)
Power input: 12V +/- 25% / 1.5A
Dimensions: 250 x 162 x 62 mm / 9.87 x 6.37 x 6.44 in
Weight: 1’525 g / 3.35 lbs. (incl. battery)
Operating temperature: (-) 10°C + 50°C / 14°F – 122°F
