Dakota — T-857-8608 Single-Element Delay Line Transducer

Overview

The Dakota T-857-8608 is a single-element delay line ultrasonic transducer designed for high-penetration thickness measurement applications. Its low 500 kHz operating frequency supports improved ultrasonic transmission through thick, attenuative, coarse-grained, or acoustically challenging materials.

Equipped with a 1 in element, the transducer provides strong acoustic energy for applications where reliable sound penetration is more important than high-resolution measurement of very thin materials. Its delay line design helps control the ultrasonic pulse and supports consistent coupling between the transducer and the inspection surface.

The top-entry BNC connector provides a secure cable connection and convenient cable routing during field, shop, manufacturing, and QA/QC inspections. SKU T-857-8608 is suitable for professional ultrasonic thickness measurement programs requiring a specialized high-penetration probe.

What's Included

Box Dimensions & Shipping Weight (Estimated)

Key Specifications

Performance Features

500 kHz High-Penetration Frequency
The low operating frequency supports improved sound transmission through thick, attenuative, coarse, or acoustically challenging materials.

1 in Single Element
The large element provides strong ultrasonic energy for demanding thickness measurement applications.

Delay Line Configuration
Helps control the ultrasonic pulse and supports consistent coupling between the transducer and the inspection surface.

Single-Element Operation
One ultrasonic element performs both sound transmission and echo reception during pulse-echo thickness measurement.

Top-Entry BNC Connection
Provides a secure connection format and convenient cable routing during field and shop inspections.

User-Friendly Design

• Top-entry connector supports practical cable positioning

• 1 in element supports stable contact on suitable inspection surfaces

• Low-frequency design supports difficult-to-penetrate materials

• Delay line configuration supports controlled ultrasonic measurement

• Compact probe format supports field and laboratory workflows

• Easy to integrate into compatible ultrasonic inspection systems

Built for Industrial Environments

• Designed for professional ultrasonic thickness measurement

• Suitable for field, manufacturing, maintenance, and QA/QC inspections

• Supports inspection of thick or acoustically attenuative materials

• Practical for specialized material evaluation workflows

• Suitable for repeated industrial inspection procedures

• Intended for use according to applicable calibration and inspection requirements

Compatibility

Compatible with:

• Ultrasonic thickness gauges that support single-element transducers

• Instruments configured for 500 kHz probe operation

• Single-probe ultrasonic cables with a compatible BNC connection

• Suitable ultrasonic couplants selected for the inspected material

• Pulse-echo ultrasonic thickness measurement procedures

• Industrial field and shop inspection systems

Instrument, cable, and frequency compatibility should be confirmed before ordering.

Ideal Applications

• Thick material measurement

• Attenuative material inspection

• Composite material evaluation

• Plastic thickness measurement

• Rubber component inspection

• Fiberglass inspection

• Coarse-grained material evaluation

• Industrial component thickness verification

• Manufacturing and fabrication QA/QC

• Preventive maintenance inspection

• Specialized ultrasonic testing applications
