NM01T2122100
5.0 MHz Dual Element Transducers, 1/4" , Hi Temp - 900F, Microdot, Top entry, T-212-2100, Dakota NDT SKU: T-212-2100
Choose Quantity
Dakota NDT — High Temperature Dual Element Transducer (5 MHz, 1/4", Microdot Top Entry)
Hi-Temp Ultrasonic Probe for Thickness Measurement & Corrosion Inspection up to 900°F SKU: T-212-2100Overview
The Dakota NDT T-212-2100 High Temperature Dual Element Transducer is a compact ultrasonic probe designed for thickness measurement and corrosion inspection on elevated-temperature surfaces. Operating at 5.0 MHz with a 1/4" diameter element, this probe provides reliable resolution for localized wall thickness checks, corrosion monitoring, and small-area inspection work.
Its dual element design uses separate transmit and receive elements to improve near-surface measurement capability and support dependable corrosion readings. The high-temperature construction allows inspection on hot components up to 900°F, making it useful for applications where shutdown or cooling may not be practical.
Equipped with a Microdot top-entry connector, this transducer supports secure signal transmission and straightforward cable routing during field, shop, and plant inspection workflows.
What's Included
| Item | Details |
|---|---|
| UT Transducer | High temperature dual element probe, 5 MHz, 1/4", Microdot top entry |
Box Dimensions & Shipping Weight (Estimated)
| Parameter | Imperial |
|---|---|
| Length | 6.0 in |
| Width | 4.0 in |
| Height | 3.0 in |
| Dimensions (L × W × H) | 6.0 × 4.0 × 3.0 in |
| Weight | 0.5 lb |
Key Specifications
| Parameter | Details |
|---|---|
| Probe Type | High temperature dual element ultrasonic transducer |
| Frequency | 5.0 MHz |
| Element Diameter | 1/4" |
| Temperature Rating | Up to 900°F |
| Connector Type | Microdot |
| Connector Location | Top entry |
| Application | Thickness measurement & corrosion inspection |
| Manufacturer | Dakota NDT |
| SKU | T-212-2100 |
Performance Features
High Temperature Capability
Designed for ultrasonic inspection on hot surfaces up to 900°F.
5 MHz Inspection Frequency
Provides reliable resolution for thickness measurement and corrosion monitoring.
Compact 1/4" Element Size
Ideal for localized inspections, small components, and restricted access areas.
Dual Element Design
Improves near-surface response and supports dependable corrosion measurements.
User-Friendly Design
- Compact probe size for precise placement
- Top-entry Microdot connector for straightforward cable routing
- Suitable for elevated-temperature inspection work
- Lightweight and practical for field use
- Designed for efficient ultrasonic testing workflows
Built for Industrial Environments
- High-temperature construction for demanding inspection conditions
- Reliable performance in field, shop, and plant environments
- Suitable for maintenance and corrosion monitoring programs
- Designed for professional NDT workflows
Compatibility
Compatible with:
- Ultrasonic thickness gauges
- Ultrasonic flaw detectors
- Dual element UT cable setups
- Microdot cable connections
- High-temperature ultrasonic couplants
- Corrosion monitoring workflows
Ideal Applications
- High-temperature thickness measurement
- Corrosion monitoring on hot components
- Pipeline and vessel inspection
- Refinery and petrochemical maintenance
- Power generation inspection
- Localized wall loss evaluation
- Manufacturing and industrial QA/QC
About Dakota NDT
Dakota NDT is a trusted manufacturer of ultrasonic testing equipment and accessories, providing reliable probes, gauges, wedges, and flaw detection solutions for professional NDT applications. Their products are widely used where accuracy, durability, and consistent inspection performance are essential.
