Dolphitec — TRM-CIx 5.0 MHz Transducer Module (8 mm Aqualene)
Ultrasonic Inspection Module for Composite & Material Evaluation SKU: C-00-2-28Overview
The Dolphitec TRM-CIx 5.0 MHz Transducer Module is a specialized ultrasonic inspection component designed for use in advanced NDT applications. Operating at 5.0 MHz, this module provides a practical balance of penetration and resolution for evaluating composites, laminates, bonded structures, and engineered materials.
Equipped with an 8 mm Aqualene interface, the TRM-CIx supports stable acoustic coupling and reliable ultrasonic signal transmission during inspection. This makes it suitable for applications requiring consistent contact, repeatable measurements, and detailed material evaluation.
Built for compatibility with Dolphitec inspection systems, this module is ideal for aerospace, manufacturing, research, and quality control environments where accurate ultrasonic imaging and material assessment are essential.
What's Included
| Item | Details |
|---|---|
| Transducer Module | TRM-CIx 5.0 MHz module with 8 mm Aqualene interface |
Box Dimensions & Shipping Weight (Estimated)
| Parameter | Imperial |
|---|---|
| Length | 8.0 in |
| Width | 6.0 in |
| Height | 3.0 in |
| Dimensions (L × W × H) | 8.0 × 6.0 × 3.0 in |
| Weight | 1.0 lb |
Key Specifications
| Parameter | Details |
|---|---|
| Product Type | Ultrasonic transducer module |
| Model | TRM-CIx |
| Frequency | 5.0 MHz |
| Interface Material | Aqualene |
| Aqualene Thickness / Size | 8 mm |
| Application | Ultrasonic inspection and material evaluation |
| Manufacturer | Dolphitec |
| SKU | C-00-2-28 |
Performance Features
5.0 MHz Inspection Frequency
Provides balanced resolution and penetration for composite and material inspection.
8 mm Aqualene Interface
Supports stable coupling and consistent ultrasonic signal transmission.
Advanced UT Inspection Support
Designed for detailed evaluation of layered, bonded, and engineered materials.
Reliable Signal Performance
Helps produce repeatable inspection results in professional NDT workflows.
User-Friendly Design
- Designed for integration with compatible Dolphitec systems
- Compact module format for practical inspection use
- Stable contact interface for consistent scanning
- Supports efficient material evaluation workflows
Built for Industrial Environments
- Reliable performance for professional NDT applications
- Suitable for laboratory, production, and field inspection settings
- Designed for repeated inspection use
- Built for composite and advanced material workflows
Compatibility
Compatible with:
- Dolphitec ultrasonic inspection systems
- Composite inspection workflows
- Bonded structure evaluation procedures
- Material testing and QA/QC programs
Ideal Applications
- Composite material inspection
- Bonded structure evaluation
- Laminate and layered material assessment
- Aerospace component inspection
- Manufacturing quality control
- Research and development testing
- Advanced ultrasonic NDT workflows
About Dolphitec
Dolphitec develops advanced ultrasonic inspection technology for composite materials, bonded structures, and industrial NDT applications. Their systems and transducer modules are used where accurate imaging, repeatable results, and dependable material evaluation are essential.
