Dakota NDT HPX DL+ High Penetration A-Scan Thickness Gauge
SKU: Z-225-0001
Dakota's most powerful A-scan thickness gauge, with high-voltage pulsers and low-frequency filters for measuring fiberglass, composites, HDPE, rubber, castings and heavy-wall steel that standard gauges can't penetrate.
| 30.5 mMax range in steel (100 ft) | 0.5–10 MHzTuned filters | 4 GBData logger memory | 383 g13.5 oz with batteries |
The Dakota NDT HPX DL+ is designed specifically for materials that are difficult for sound to penetrate, due to the lack of material consistency, grain structure or overall thickness. Multiple high-voltage pulser options and filters tuned for lower-frequency transducers (500 kHz to 10 MHz) let it measure fiberglass, carbon fiber, cast metals, rubber, HDPE, FRP, lead, and all steels and aluminums.
An A-scan waveform display lets inspectors verify every reading, and a built-in data logger with 4 GB of internal memory documents every survey. The kit comes ready to work with a custom 1" rubber delay line transducer, PC software and a foam-fitted carrying case.
Key Features
 | Power to penetrate difficult materialsPowerful high-voltage spike, square wave and tone burst pulsers drive low-frequency transducers deep into attenuative materials, and filters optimized for 500 kHz to 10 MHz help secure the back wall echo. It measures composites over 100 mm thick and steel up to 100 ft (30.5 m). |
A-scan verification and data loggingView the A-scan waveform to confirm every reading on difficult materials, with gain slope control and a 25 Hz screen refresh for a responsive display. A built-in data logger with grid and sequential file formats stores readings on 4 GB of internal SD memory. |  |
Built for the Field
Delay line transducer included
The kit's custom 1" × 0.5 MHz single-element rubber delay line transducer is built for high-penetration work on composites, plastics and other attenuative materials.
Fast, FPGA-driven platform
The FPGA-driven electronics deliver speed and accuracy, and the 25 Hz screen refresh keeps the gauge responsive while you scan.
Selectable resolution and wide velocity range
Choose 0.01" (0.1 mm) or 0.001" (0.01 mm) resolution, and set velocities from 310 to 18,542 m/s to suit virtually any material.
Easy reporting
Connect to a Windows PC or Mac over USB-C, and use Dakota's free reporting software to manage and report your data.
Rugged and compact
An extruded aluminum body with gasket-sealed, nickel-plated end caps weighs just 383 g (13.5 oz) with batteries and works from -10°C to 60°C. It runs on AA batteries or USB power.
Specifications
| General | |
| Manufacturer | Dakota NDT |
|---|---|
| Model | HPX DL+ |
| SKU | Z-225-0001 |
| Instrument type | High penetration A-scan ultrasonic thickness gauge |
| Warranty | 2 years |
| Shipping dimensions (estimated) | 356 × 254 × 152 mm (14.0 × 10.0 × 6.0 in) |
| Shipping weight (estimated) | 2.3 kg (5.0 lb) |
| Measurement | |
| Measurement mode | Pulse-echo, contact and delay line |
| Range in steel | 0.05 in to 100 ft (1.27 mm to 30.5 m), depending on transducer |
| Range in composites | Approximately 2.5 to 127 mm (0.1 to 5 in) |
| Resolution | Selectable: 0.01 in (0.1 mm) or 0.001 in (0.01 mm) |
| Velocity range | 0.0122 to 0.73 in/µs (310 to 18,542 m/s) |
| Pulsers | Multiple high-voltage options: spike, square wave and tone burst |
| Filters | Tuned for 500 kHz to 10 MHz transducers |
| Gain | Manual or AGC; gain slope |
| Materials | Fiberglass, carbon fiber, cast metals, rubber, HDPE, FRP, lead, all steels and aluminums |
| Display & Data | |
| Display | EL backlit (on, off, auto, invert); 25 Hz refresh |
| Views | A-scan waveform, B-scan and large digits |
| Data logger | Grid and sequential file formats; 4 GB internal SD memory |
| Connectivity | USB-C; Windows PC and Mac OSX reporting software (free download) |
| Physical | |
| Size (W × H × D) | 63.5 × 165 × 31.5 mm (2.5 × 6.5 × 1.24 in) |
| Weight | 383 g (13.5 oz) with batteries |
| Case | Extruded aluminum body with nickel-plated aluminum end caps, gasket sealed |
| Keyboard | Membrane switch pad with 12 tactile keys |
| Power | AA batteries or USB power |
| Operating temperature | -10°C to 60°C (14°F to 140°F) |
What's in the Box
- Dakota NDT HPX DL+ thickness gauge
- Custom 1" × 0.5 MHz rubber delay line transducer (T-857-8608) and cable
- Couplant
- AA batteries
- Data transfer cable and PC software (download)
- Foam-fitted carrying case
- Operation manual
- Certificate of calibration
Standard Dakota NDT kit. Contents can vary by package, so contact us to confirm what ships with your order.
Complete your thickness testing setup
Add Dakota low-frequency contact and delay line transducers for other materials and thicknesses, extra couplant, a reference block of your material, and the protective rubber boot for tall-format Dakota gauges.
Applications
The HPX DL+ handles thickness measurement on materials that standard thickness gauges struggle to penetrate.
| ✓ Fiberglass sheets and pipes | ✓ FRP storage tanks |
| ✓ Aerospace composites | ✓ Boat hulls |
| ✓ Conveyor belts and rubber | ✓ HDPE and composite plastics |
| ✓ Cast metals | ✓ Heavy-wall steel and aluminum |
About Dakota NDT
Dakota NDT, an Elcometer company, manufactures high-quality industrial ultrasonic testing equipment for the petrochemical, aerospace, power generation and automotive industries. Its range includes corrosion and precision thickness gauges, flaw detectors, bolt tension monitors, transducers and accessories.
