NM01IQI102505

Ensure the integrity and reliability of your radiographic inspections on Carbon Steel, Aluminum, and Stainless Steel with the Stainless Steel IQI Hole Penetrameter #05. This essential quality control tool is meticulously manufactured to meet the stringent requirements of ASME SE-1025, ASTM E-1025, API 1104, and AWS standards, guaranteeing compliance and accurate assessment of your radiographic image quality.

This penetrameter, identified with the #05 designation, features precisely drilled holes with diameters of 1T, 2T, and 4T relative to its nominal thickness of 0.005 inches. These calibrated holes serve as indicators of the radiographic sensitivity achieved during your inspections, allowing you to confidently evaluate the smallest detectable flaw size.

Constructed from durable Stainless Steel, this IQI ensures material compatibility with the Group A materials it is intended for, providing accurate and reliable results. By including this penetrameter in your radiographic procedures, you can verify the effectiveness of your techniques, meet critical industry specifications, and ensure the safety and quality of your inspected components.

Key Features:

• Complies with Key Industry Standards: Meets the requirements of ASME SE-1025, ASTM E-1025, API 1104, and AWS.

• Specifically for Group A Materials: Ideal for Carbon Steel, Aluminum, and Stainless Steel inspections.

• Precise Hole Diameters (1T, 2T, 4T): Allows for accurate assessment of radiographic sensitivity.

• Durable Stainless Steel Construction: Ensures material compatibility and long-lasting performance.

• Clearly Marked: Features the penetrameter number (#05) and material identification.

• Essential for Quality Assurance: Verifies the effectiveness of radiographic techniques.

Applications:

• Radiographic inspection of welds in pipelines and structural components.

• Quality control of castings and forgings.

• Evaluation of radiographic techniques in manufacturing processes.

• Compliance with industry regulations for radiographic testing of Group A materials.

• Training and education in radiographic inspection procedures.
