NM01AVEII

The NDT Systems AVENGER EZ is a lightweight yet rugged ultrasonic flaw detector intended for everyday use in evaluating materials across various industries. It's well-suited for the inspection of investment castings, in-service equipment, plastics, turbine blades, tanks, tubes, and pipes. The Avenger EZ is designed to provide accurate and reliable measurements for sizing subsurface defects in a wide range of solid materials.

A key feature of the AVENGER EZ is its SplitScan View, which allows for the simultaneous display of both the A-Trace (the raw ultrasonic signal) and a real-time B-Scan (a cross-sectional view of the material being inspected, often used for corrosion mapping and visualizing the depth and extent of flaws). This dual display provides the operator with immediate feedback and aids in the identification and interpretation of indications.

The instrument offers several user-friendly features, including AutoTrack, which automatically tracks and zooms in on a selected echo, making it easier to monitor and analyze specific indications. It also typically includes multiple gate capabilities for precise flaw detection and sizing.

The AVENGER EZ supports various transducer types, including single and dual element transducers, and often features automatic probe recognition or the ability to select probes from a library. It has adjustable gain, damping controls, and a wide frequency range, allowing it to be used for a broad spectrum of materials and inspection requirements.

Data logging capabilities are usually included, allowing users to store waveforms, B-Scans, and setups for documentation and analysis. Connectivity options like USB are typically available for data transfer to a PC.

Some versions of the AVENGER EZ, such as the AVENGER EZ AWS, are specifically designed to meet or exceed the requirements of the American Welding Society (AWS) standards for weld inspection. These versions may include AWS-compliant features and software for automated D-value calculations.

Key Features:

• Lightweight and Handheld: Designed for portability and ease of use in the field.

• SplitScan View: Simultaneous display of A-Trace and real-time B-Scan.

• AutoTrack: Automatic tracking and zoom of selected echoes.

• Multi-Gate Capability: Allows for precise flaw detection and sizing.

• Automatic Probe Recognition or Library Selection: Simplifies setup.

• Adjustable Gain and Damping: Optimizes the signal for different materials and applications.

• Wide Frequency Range: Typically from 0.5 MHz to 15 MHz, suitable for various inspections.

• Data Logging: Storage of waveforms, B-Scans, and setups.

• USB Connectivity: For data transfer and software updates.

• AWS Compliance (in some models): Meets or exceeds American Welding Society standards for weld inspection.

• SplitView: Dual Timebase feature allowing simultaneous viewing of the full range and a zoomed-in section.

• Screen Freeze Mode: To hold and analyze the displayed waveform.

• Alarm Modes: For indication of thickness or amplitude thresholds.

• Programmable User Setups: For quick recall of frequently used parameters.

Applications:

• Evaluation of investment castings.

• In-service inspection of various structures and components.

• Inspection of plastics, composites, glass, and rubber.

• Turbine blade inspection.

• Tank and boiler inspection.

• Tube and pipe inspection.

• Corrosion mapping.

• Weld inspection (especially with AWS compliant models).

• Thickness measurement.
