Adelix ADL MS52-A Laser Alignment System: Precision Shaft Alignment for Optimal Machine Performance

Achieve unparalleled accuracy and extend the lifespan of your rotating machinery with the Adelix ADL MS52-A Laser Alignment System. This intuitive, high-precision instrument is designed to quickly and efficiently perform horizontal and vertical shaft alignment, significantly reducing vibration, bearing failures, and energy consumption in a wide range of industrial applications.

Key Features & Benefits:

• Wireless Laser Sensors: Features ultra-light, compact, and wireless laser sensors with integrated Bluetooth connectivity, allowing for flexible positioning and unrestricted movement around the machine during alignment.

• High Precision Measurements: Employs advanced laser technology to deliver highly accurate alignment measurements, ensuring machinery is set up to optimal tolerances.

• Intuitive User Interface: The main display unit (often featuring a color screen) provides a clear, step-by-step graphical interface that guides the user through the alignment process, making it accessible even for less experienced technicians.

• Comprehensive Alignment Functions: Includes essential functions for both horizontal and vertical machine alignment. Often features:

  • Live Mode: Real-time feedback for dynamic adjustments.

  • Soft Foot Check: Helps identify and correct common machine base problems.

  • Thermal Growth Compensation: Accounts for changes in alignment due to thermal expansion/contraction during operation.

  • Gasket Simulator: Allows for pre-determining the effect of shims.

• Wide Application Range: Accommodates a broad range of shaft diameters (typically 20 to 250 mm or more with supplied V-brackets and chains) and measurement distances (often up to 10 meters / 33 ft), suitable for small pumps to large turbines.

• Data Storage and Reporting: Capable of storing measurement results and generating detailed alignment reports (often in PDF format), essential for record-keeping, analysis, and compliance.

• Rugged & Portable Design: Built for demanding industrial environments, often featuring an IP54-rated main unit and IP68-rated sensors, ensuring durability and reliability in the field. The entire system typically comes in a sturdy, portable carrying case.

• Long Battery Life: Powered by efficient rechargeable batteries, providing ample operating time for extensive alignment tasks.

• Complete System: The typical delivery set includes the display unit, two wireless laser sensors, two universal V-brackets with chains, a charger, USB cable, software on a flash drive, measuring tape, and a robust protective case.

The Adelix ADL MS52-A Laser Alignment System is an indispensable tool for maintenance managers, reliability engineers, and field technicians in manufacturing, petrochemical, power generation, and marine industries, providing the precision needed to optimize machinery performance and minimize costly breakdowns.
