NM01PAUTIIW.ISO19675.CS

The PH Tool PAUT IIW Block is a precision-engineered reference standard specifically designed for the calibration and verification of Phased Array Ultrasonic Testing (PAUT) systems. Manufactured in accordance with ISO 19675 standards, this block is an essential tool for ensuring accurate and reliable PAUT inspections across various industries.

Constructed from high-quality AISI 1018 steel, this block offers consistent and predictable ultrasonic response. The nickel-plated finish provides enhanced corrosion resistance and a smooth, durable surface for repeated use.

This specific block features the following dimensions: 25mm wide x 100mm tall x 300mm long. It also incorporates precise geometric features, including 100mm and 50mm radii, which are crucial for calibrating beam steering and focusing capabilities in PAUT.

Furthermore, the block contains strategically placed Side-Drilled Holes (SDHs) of specific diameters: four holes with a 3.0mm diameter and one hole with a 1.6mm diameter. These precisely sized reflectors are used to evaluate the sensitivity, resolution, and beam characteristics of PAUT probes and systems.

Manufactured by PH Tool, a recognized leader in the production of high-quality NDT calibration standards, this PAUT IIW block guarantees dimensional accuracy and adherence to the ISO 19675 specification.

Key Selling Points:

• Complies with ISO 19675: Ensures adherence to a globally recognized standard for PAUT calibration blocks.

• High-Quality AISI 1018 Steel: Provides consistent and reliable ultrasonic response.

• Durable Nickel-Plated Finish: Offers enhanced corrosion resistance and a smooth surface.

• Precise Geometric Features: Includes 100mm and 50mm radii for accurate beam steering calibration.

• Strategically Placed SDHs: Features four 3.0mm and one 1.6mm diameter holes for comprehensive system evaluation.

• Manufactured by PH Tool: Guarantees high quality and dimensional accuracy.

Benefits:

• Ensures Accurate PAUT Inspections: Allows for proper calibration and verification of PAUT systems.

• Facilitates Compliance with International Standards: Meets the requirements of ISO 19675.

• Improves Inspection Reliability: Provides a consistent reference standard for repeatable results.

• Versatile Calibration Capabilities: Enables comprehensive evaluation of PAUT probe and system performance.

• Durable and Long-Lasting: High-quality materials and construction ensure extended service life.

Applications:

• Calibration and performance verification of Phased Array Ultrasonic Testing (PAUT) equipment.

• Training and qualification of PAUT personnel.

• Research and development in PAUT techniques.

• Quality control in industries utilizing PAUT for critical inspections, such as:

  • Oil & Gas

  • Aerospace

  • Power Generation

  • Manufacturing

The PH Tool PAUT IIW Block, ISO 19675 is an indispensable tool for ensuring the accuracy and reliability of your Phased Array Ultrasonic Testing inspections. Its precise design and high-quality construction make it a valuable asset for any organization utilizing advanced ultrasonic techniques.
