NM01UTCNDMMDA5

This high-quality 5-foot (1.52m) ultrasonic probe cable is a versatile and essential accessory for a wide range of NDT (Non-Destructive Testing) ultrasonic thickness gauges and flaw detectors. Specifically designed to provide a reliable connection between your instrument and dual-element transducers, it features a DM Plug (often associated with Krautkramer/Waygate Technologies DM series gauges) on one end and dual Microdot connectors on the other. This configuration, similar to the KBA531 cable used for KBA560 type probes, makes it compatible with many popular dual-element probes requiring separate input/output connections.

Constructed with RG-174 coaxial cable, this cable offers excellent flexibility for navigating tight inspection areas while maintaining signal integrity. The inclusion of both "Large" and "Standard" Microdot connectors, along with a protective rubber grommet, ensures broad compatibility and enhanced durability in demanding industrial environments.

Key Features & Benefits:

• Universal Compatibility: Features a common DM plug for connection to instruments (e.g., Krautkramer DM series, some Olympus models) and dual Microdot connectors for a wide range of dual-element ultrasonic probes.

• Dual Microdot Configuration: Includes both "Large" and "Standard" Microdot connectors, offering flexibility for various probe types requiring separate send/receive connections.

• RG-174 Coaxial Cable: Utilizes thin, flexible, and durable RG-174 coaxial cable, making it easy to maneuver in tight spaces and reducing cable fatigue.

• Optimal Length: A 5-foot (1.52m) length provides a good balance between reach and manageability for most ultrasonic inspection tasks.

• Signal Integrity: 50 Ohm impedance ensures efficient signal transmission for accurate and reliable ultrasonic readings.

• Robust Construction: Designed for industrial use, offering resistance to common wear and tear.

• Protective Rubber Grommet: Enhances cable durability and provides strain relief at the connector, extending the cable's lifespan.

• Similar to KBA531: Functions similarly to the KBA531 cable, making it a suitable replacement or alternative for instruments and probes requiring that connector configuration.

Technical Specifications (Approximate):

• Cable Type: RG-174 Coaxial Cable

• Length: 5 feet (approx. 1.52 meters)

• Impedance: 50 Ohms

• Instrument Connector: DM Plug (compatible with many Krautkramer DM series, some Olympus UT gauges)

• Probe Connectors: Dual Microdot (one Large, one Standard)

• Cable Diameter (RG-174): Approx. 2.8 mm (0.11 inches)

• Minimum Bend Radius (RG-174): Approx. 6.35 mm (0.25 inches)

• Operating Temperature (RG-174): Typically -40°C to 80°C (-40°F to 176°F)

• Included: Rubber grommet for strain relief/protection.

Applications:

• Ultrasonic Thickness Gauging

• Ultrasonic Flaw Detection

• Corrosion Mapping

• General NDT applications requiring dual-element ultrasonic probes.

• Compatibility with instruments and probes requiring DM and Microdot connections.

Ensure reliable connections for your ultrasonic inspections. Equip your NDT toolkit with this high-quality DM Plug to Dual Microdot probe cable.
