General Purpose Dual Element Transducer, top-mounted microdot connectors, 5 MHz, 0.375", NDT-SYSTEMS SKU: TG-506
Choose Quantity
NDT Systems — General Purpose Dual Element Transducer (5 MHz, 0.375")
Dual Element UT Probe with Top-Mounted Microdot Connectors SKU: TG-506Overview
The NDT Systems TG-506 is a general-purpose dual-element ultrasonic transducer designed for accurate thickness measurement and corrosion inspection in a wide range of industrial applications. Operating at 5 MHz with a 0.375" element size, this probe provides an excellent balance between penetration and resolution, making it suitable for both general inspection and corrosion monitoring tasks.
Featuring dual-element (transmit/receive) technology, the TG-506 enhances near-surface resolution and delivers reliable readings on rough, pitted, or coated surfaces. The top-mounted microdot connectors ensure secure signal transmission and provide convenient cable management during inspections.
Engineered for versatility and durability, this transducer is compatible with a variety of ultrasonic thickness gauges and flaw detectors, making it an ideal choice for professionals in oil & gas, power generation, and manufacturing industries.
What's Included
| Item | Details |
|---|---|
| Dual Element Transducer | 5 MHz, 0.375" UT probe with microdot connectors |
| Connector Interface | Dual microdot (top-mounted) |
| Protective Case | Storage and transport protection (if applicable) |
Box Dimensions & Shipping Weight (Estimated)
| Parameter | Imperial |
|---|---|
| Length | 6.0 in |
| Width | 4.0 in |
| Height | 3.0 in |
| Dimensions (L × W × H) | 6.0 × 4.0 × 3.0 in |
| Weight | 0.6 lb |
Key Specifications
| Parameter | Details |
|---|---|
| Probe Type | Dual-element ultrasonic transducer |
| Frequency | 5 MHz |
| Element Size | 0.375 in |
| Connector Type | Dual microdot (top-mounted) |
| Configuration | Dual element (transmit/receive) |
| Application | Thickness measurement and corrosion inspection |
Performance Features
Dual-Element Design
Improves near-surface resolution and provides accurate readings on rough or coated surfaces.
Balanced Frequency Performance
5 MHz frequency offers an optimal combination of penetration and resolution for general-purpose inspections.
Top-Mounted Microdot Connectors
Ensures secure connections while improving cable routing and ease of use.
Reliable Measurement Accuracy
Delivers consistent and repeatable results across a wide range of applications.
User-Friendly Design
- Easy connection to compatible UT instruments
- Compact and ergonomic design
- Lightweight for extended use
- Suitable for field and workshop inspections
Built for Industrial Environments
- Durable construction for demanding applications
- Designed for corrosion and thickness inspection
- Reliable performance in continuous use
- Suitable for field and plant environments
Compatibility
Compatible with:
- Ultrasonic thickness gauges
- Flaw detectors with microdot connectors
- Corrosion monitoring systems
- Industrial UT inspection workflows
Ideal Applications
- General thickness measurement
- Corrosion monitoring of pipes and tanks
- Inspection of coated and rough surfaces
- Oil & gas and power generation industries
- Manufacturing and maintenance inspections
- General ultrasonic testing (UT)
